AMD Ryzen 7 8700F 8th Generation Processor ( 4.1 GHz / 8cores / 16Threads )

The AMD Ryzen 7 8700F is an eight-core, sixteen-thread desktop processor built on the Zen 4 (Phoenix) architecture and fabricated using TSMC's 4nm FinFET process. It sits in the Ryzen 8000 series and targets AM5 motherboards, making it forward-compatible with the AM5 platform ecosystem. The chip operates at a base clock of 4.1 GHz and can reach a maximum boost frequency of up to 5 GHz through Precision Boost 2, AMD's automated frequency-scaling technology that responds to workload demands in real time. With 8 MB of L2 cache and 16 MB of L3 cache, the 8700F maintains a healthy data buffer for gaming, content creation, and productivity workloads. AMD Simultaneous Multithreading (SMT) doubles the effective thread count to 16, enabling more parallelism across multi-threaded applications. The processor's unlocked multiplier and support for Precision Boost Overdrive, Curve Optimizer voltage offsets, and AMD EXPO memory overclocking technology give enthusiasts multiple tuning levers without requiring specialist tools — AMD Ryzen Master software provides a graphical interface for adjusting settings from within Windows. The 8700F does not include integrated graphics; a discrete graphics card is required. However, when paired with a compatible AMD Radeon graphics card, AMD SmartAccess Memory and AMD Ryzen AI features become available. The chip Neural Processing Unit (NPU) is rated at up to 16 TOPS, enabling AI-accelerated software experiences when combined with a Radeon GPU. Memory support is DDR5-only via a dual-channel interface, with a maximum officially supported speed of DDR5-5200 in a two-DIMM single-rank or dual-rank configuration, and up to DDR5-3600 in a four-DIMM configuration. Maximum system memory capacity is 256 GB using UDIMM modules. The platform also provides PCIe 4.0 connectivity with 20 total lanes (16 usable), two native USB 4 (40 Gbps) ports, two USB 3.2 Gen 2 (10 Gbps) ports, and one USB 2.0 port. NVMe storage supports Boot, RAID0, and RAID1 configurations. Verified Specifications: - Architecture: Zen 4 (Phoenix) | Process: TSMC 4nm FinFET - Cores / Threads: 8 / 16 | Base Clock: 4.1 GHz | Max Boost: Up to 5 GHz - L2 Cache: 8 MB | L3 Cache: 16 MB | Default TDP: 65W | cTDP: 45–65W - Socket: AM5 | Memory: DDR5 (dual-channel), max DDR5-5200, up to 256 GB - PCIe: 4.0 (20 lanes total, 16 usable) | NPU: Up to 16 TOPS - OS Support: Windows 11/10 (64-bit), RHEL x86 64-bit, Ubuntu x86 64-bit - Max Operating Temperature (Tjmax): 95°C | Warranty: 3 years - Part Number: 100-100001590BOX
