Ant Esports Box C Air Grey M-ATX Mini Tower Case
MPN BOX-C-AIR-GREY · Brand Ant Esports · mATX, Mini-ITX
The Ant Esports Box C Air Grey is a compact Micro-ATX/Mini-ITX mini tower case featuring a front mesh panel, tempered glass side window, pre-installed rear fan, USB Type-C front I/O, and support for GPUs up to 335 mm and CPU coolers up to 168 mm
Inclusive of GST · GST invoice available
Overview
The Ant Esports Box C Air Grey is a compact Micro-ATX and Mini-ITX compatible mini tower cabinet designed for budget-conscious builders who want a clean, functional chassis without unnecessary bulk. The front mesh panel promotes steady passive airflow into the system, helping keep components cooler during demanding workloads. A full-panel tempered glass side window lets you view your build's internals without removing the side panel, adding a visual dimension to an otherwise practical enclosure. Inside, the case offers enough room for most mainstream components. A pre-installed 120 mm fan at the rear provides immediate exhaust airflow straight out of the box, and an additional 120 mm fan can be mounted at the front for a balanced push-pull setup. The chassis accepts graphics cards up to 335 mm in length, covering a wide range of mid-range discrete GPUs, and accommodates CPU coolers up to 168 mm tall, making it compatible with many tower air coolers currently available in the market. Storage capacity covers everyday needs with one 3.5-inch drive bay for a traditional hard disk and two 2.5-inch bays for solid-state drives, giving builders flexibility to combine fast boot storage with bulk storage in a single system. The front I/O panel is well-equipped for a case at this price tier, featuring one USB 3.0 Type-A port, one USB Type-C port, and a combined 3.5 mm audio and microphone TRRS jack alongside the power button. Four expansion slots are available at the rear to accommodate multi-slot GPUs or add-in cards. The cabinet body is constructed from ABS plastic and steel (SPCC), with a tempered glass side panel providing structural variety and a premium visual element. The chassis measures 378 mm (L) × 195 mm (B) × 290 mm (H) and carries a 1-year manufacturer warranty. Verifiable Specifications: - Form Factor: Micro-ATX, Mini-ITX - Chassis Dimensions (L × B × H): 378 × 195 × 290 mm - Materials: ABS, SPCC steel, Tempered Glass - Drive Bays: 1 × 3.5", 2 × 2.5" - Fan Support: 1 × 120 mm (front), 1 × 120 mm (rear) - Pre-Installed Fan: 1 × 120 mm rear - Max GPU Length: 335 mm - Max CPU Cooler Height: 168 mm - Expansion Slots: 4 - Front I/O: 1 × USB 3.0, 1 × USB Type-C, 1 × Audio + Mic TRRS, Power Button - Warranty: 1 Year
Datasheet
| Warranty | 1 Year |
|---|---|
| Form Factor | mATX, Mini-ITX |
| color | Grey |
| Note*** | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only |
| Material | ABS, SPCC, Tempered Glass |
| I/O Panel | 1 x USB 3.0, 1 x Type-C, 1 x Audio + Mic TRRS Port, Power Button |
| Materials | ABS + SPCC+Tempered Glass |
| Drive Bays | 1 x 3.5"and 2 x 2.5" |
| Model | Ant Esports Box C Air Mid-Tower Computer Case |
| Fan Support | 120 mm x 1 -Front 120mm x1 – Rear |
| Cabinet Size | MINI-TOWER |
| Max 2.5" SSD | 2 |
| Max 3.5" HDD | 1 |
| Max GPU Length | 335mm |
| Expansion Slots | 4 |
| Front I/O Panel | USB 3.0, USB Type-C, Audio, Mic TRRS Port, Power Button |
| Max Fan Support | 2 |
| Vga Card Length | 335 mm |
| Motherboard Type | Micro-ATX, Mini-ITX |
| CPU Cooler Height | 168 mm |
| Pre-Installed Fan | 1 Rear Fan |
| Pre Installed Fans | 1 |
| Max CPU Cooler Height | 168mm |
| Chassis Size(L X B X H) | 378 x 195 x 290 mm |
