Ant Value VM45 M-ATX Mini Tower Case
MPN VM45-BLACK · Brand Ant Esports · mATX, Mini-ITX
The Ant Value VM45 is a Micro-ATX/Mini-ITX mini tower case featuring four pre-installed 120mm fans, a full-mesh front panel, tempered glass side panel, and support for GPUs up to 280mm and a 240mm top radiator
Inclusive of GST · GST invoice available
Overview
The Ant Value VM45 is a compact Micro-ATX and Mini-ITX compatible mini tower case from Ant Esports, built for users who need strong thermal performance and clean aesthetics without occupying a large footprint. Its full-mesh front panel promotes unrestricted airflow from the moment you power while the tempered glass side panel lets you display your components and lighting in full view. Out of the box, the VM45 ships with four 120mm fans — three mounted at the front as intake and one at the rear as exhaust — delivering solid positive-pressure airflow without any additional purchases. Builders who want to go further can mount additional fans or a 240mm liquid-cooling radiator on the top, or explore the supported 140mm and 120mm radiator positions for alternative cooling configurations. A top-mounted dust filter helps keep intake debris out of the system. Despite its compact 295 × 190 × 405 mm footprint, the VM45 accommodates a respectable range of hardware. Graphics cards up to 280mm in length fit comfortably, and CPU tower coolers up to 160mm tall are supported, covering most mainstream air coolers. Storage options include one 3.5-inch HDD bay and one 2.5-inch SSD bay. Four expansion slots serve the rear I/O needs of most M-ATX builds. The front I/O panel provides everyday convenience with a USB 3.0 port, two USB 2.0 ports, HD Audio and microphone jacks, power and reset buttons, and dedicated power and hard drive activity indicators. The chassis is constructed from steel with a tempered glass side panel, giving it a rigid build at an accessible price point. Verified Specifications: - Form Factor Support: Micro-ATX, Mini-ITX - Dimensions: 295 × 190 × 405 mm - Pre-Installed Fans: 4 × 120mm (3 front intake, 1 rear exhaust) - Maximum Fan Support: 8 total - Radiator Support: Top 240mm / 140mm / 120mm - Max GPU Length: 280mm - Max CPU Cooler Height: 160mm - Drive Bays: 1 × 3.5-inch HDD, 1 × 2.5-inch SSD - Expansion Slots: 4 - Dust Filters: Top - Front I/O: USB 3.0 × 1, USB 2.0 × 2, HD Audio, Mic, Power & Reset buttons, Power & HDD indicators - Side Panel: Tempered Glass - Materials: Steel, Tempered Glass - Color: Black - Warranty: 1 Year
Datasheet
| Warranty | 1 Year |
|---|---|
| Form Factor | mATX, Mini-ITX |
| color | Black |
| Note*** | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only |
| Material | Steel,Tempered Glass |
| Cabinet Size | MINI-TOWER |
| Dust Filters | Top |
| Max 2.5" SSD | 1 |
| Max 3.5" HDD | 1 |
| Max GPU Length | 280mm |
| Expansion Slots | 4 |
| Front I/O Panel | USB 3.0, 2 x USB,HD Audio,Mic,Power & Reset Button,Power & Hard Drive Indicators |
| Max Fan Support | 8 |
| Radiator Support | 240mm,140mm,120mm |
| Pre Installed Fans | 4 |
| Max CPU Cooler Height | 160mm |
