Features of ANTEC Dark Phantom DP502 Flux ATX Mid Tower Cabinet (Black)
The ANTEC PC Cabinet case is well equipped with an industry-leading design of advanced ventilation, taking the Antec Dark league gaming cases to the next generation.
Why the New Cooling Solution?
When Intel and AMD announced their latest CPUs, they all deliver remarkable performance upgrades and better productivity, it also means the functional requirement of PC equipment needs to be taken to the next level, especially the thermal performance.
To cope with the stress of enhanced heat dissipation, Antec developed a revolutionary structure for airflow, providing an improved and powerful cooling solution for your system. ANTEC Dark Phantom DP502 Flux Mid Tower ATX cabinet
F-LUX Platform – Antec’s Original Cooling Solution. What is the F-LUX Platform?
The definition of FLUX is Flow Luxury. The F-LUX Platform is a new industry-leading and highly efficient design by Antec featuring an advanced case structure for excellent airflow and 5 x 120 mm fans included. A core element of the design ethos was to enhance GPU cooling performance.
Color Your System by Built-in LED Controller
You only need the LED mode button to control all the addressable LEDs.
Or you can sync it with the motherboard to enjoy more custom light effects.
Make a Green Build
7 Reusable PCI-E Slots.
Specifications of ANTEC Dark Phantom DP502 Flux ATX Mid Tower Cabinet (Black)
| Dimensions | 463 x 220 x 486 mm (DWH) |
| Form Factor | Mid Tower |
| Materials | Steel + Plastic |
| Mainboard Support | ATX, M-ATX, ITX |
| Front Access & Controls | Power, LED Control Button, 2 x USB3.0, HD-AUDIO |
| Side Panel | 4 mm Tempered Glass Side Panel |
| Expansion & Drive Bays | |
| Expansion Slots | 7 |
| 5.25″ | 1 |
| 3.5″ /2.5″ | 3/2 |
| 2.5″ | 3 |
| Fan | |
| Front | 3 x 120mm/2 x 140mm |
| Top | 3 x 120mm / 2 x 140mm (w/o ODD and w/o ODD bracket) 2 x 120mm / 2 x 140mm (w/o ODD but with ODD bracket) 2 x 120mm / 1 x 140mm(When ODD is installed) |
| Power Supply Shroud | 2 x 120mm |
| Rear | 1 x 120mm |
| Pre-installed Fans | 3 x 120mm ARGB fans in front 1 x 120mm fan (Reverse Fan) on PSU shroud & 1 x 120mm fan in rear |
| Radiator Support | |
| Front | 120/240/280/360mm (≤ 55mm thickness when fans are installed outside of front panel) (≤ 30mm thickness when fans are installed inside of front panel) |
| Top | 240/280/360mm (w/o ODD and w/o ODD bracket) 240/280mm (w/o ODD but with ODD bracket) 120mm(When ODD is installed) |
| Rear | 120mm |
| Clearance | |
| Max GPU Length | ≤ 405mm |
| Max CPU Cooler Height | ≤ 175mm |
| Max PSU Length | ≤ 205mm |
| Miscellaneous | |
| Dust Filter | Front / Top / Bottom / Right Hand Side |
| Net Weight | 7.55KG |
| Gross Weight | 8.7KG |
| Warranty | 2 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
