MPN ANTEC-NE700G-ZEN-SMPS · Brand ANTEC
Features of ANTEC NE700G ZEN The new ANTEC NeoECO Gold ZEN 700W Power Supply high performance with an 80 PLUS Gold rating, achieving up to 92% efficiency and gives you savings unheard of from other power supplies. Featuring a 120mm whisper-quiet high-quality fan and CircuitShield™ Industrial Grade Protection-all backed up by our 5-year Antec Quality Warranty, NeoECO Gold ZEN pc power supply offers a highly efficient, affordable power solution. Antec 5-Year Warranty We stand by the quality and sa
Inclusive of GST · GST invoice available
The new ANTEC NeoECO Gold ZEN 700W Power Supply high performance with an 80 PLUS Gold rating, achieving up to 92% efficiency and gives you savings unheard of from other power supplies. Featuring a 120mm whisper-quiet high-quality fan and CircuitShield™ Industrial Grade Protection-all backed up by our 5-year Antec Quality Warranty, NeoECO Gold ZEN pc power supply offers a highly efficient, affordable power solution.
Features a Thermal Manager, an advanced low voltage fan control for optimal heat & noise management and will allow your PSU to stay at an optimal temperature.
Engineered with high-quality capacitors and low-noise transformers, the NeoECO Gold ZEN series provide clean, stable power with maximum CPU & GPU support
| Model | NE700G Zen |
| Type | ATX 12V 2.4 |
| Modular | － |
| Dimension | 140(L) x 150(W) x 86(H) |
| Warranty | 5 years |
| Input Voltage | 100-240 VAC |
| Input Current | 10A-5A |
| Input Frequency Range | 50Hz-60Hz |
| PFC | Active PFC |
| Power Good Signal | 100-500ms |
| Efficiency | Up To 92% |
| Protection | OCP/OVP/UVP/SCP/OPP/NLO |
| Output Capacity | 700W |
| Operation Temperature | 0~40°C |
| Regulatory | cTUVus/TUV/CB/RCM/CE/CCC/BSMI/FCC/KC |
| Fan | 120mm Silence Fan |
| Certifications | 80 Plus Gold |
|
Connector
|
1 x MB 24(20 4) Pin |
| 2 x 8(4 4) Pin EPS 12V | |
| 4 x 8(6 2) Pin PCI-E | |
| 6 x SATA | |
| 2 x Molex | |
| Net Weight | 1.79 Kgs |
| Gross Weight | 2.17 Kgs |
|
UPC#
|
0-761345-11686-2 NE700G ZEN |
| 0-761345-11687-9 NE700G ZEN AU | |
| 0-761345-11688-6 NE700G ZEN EC | |
| 0-761345-11689-3 NE700G ZEN GB | |
| 0-761345-11690-9 NE700G ZEN JP |
| Warranty | 5 Years |
|---|---|
| Fan | 120mm Silence Fan |
| Pfc | Active PFC |
| Model | NE700G Zen |
| Modular | － |
| Connector | 1 x MB 24(20 4) Pin |
| Dimension | 140(L) x 150(W) x 86(H) |
| Efficiency | Up To 92% |
| Net Weight | 1.79 Kgs |
| Protection | OCP/OVP/UVP/SCP/OPP/NLO |
| Regulatory | cTUVus/TUV/CB/RCM/CE/CCC/BSMI/FCC/KC |
| Gross Weight | 2.17 Kgs |
| Input Current | 10A-5A |
| Input Voltage | 100-240 VAC |
| Certifications | 80 Plus Gold |
| Output Capacity | 700W |
| Power Good Signal | 100-500ms |
| Input Frequency Range | 50Hz-60Hz |
| Operation Temperature | 0~40°C |
