ARCTIC Freezer 8A Single-Tower CPU Air Cooler for AMD AM5 & AM4

The ARCTIC Freezer 8A (SKU: ACFRE00161A) is a compact single-tower CPU air cooler built exclusively for AMD AM4 and AM5 platforms. Its modest footprint — 83 mm (L) × 108 mm (W) × 136 mm (H) — makes it a practical choice for small-form-factor and mid-tower cases where clearance around tall RAM modules or adjacent PCIe slots is a genuine concern. At the core of the cooler are two 6 mm copper heatpipes arranged in a direct-touch, offset layout. The offset orientation is deliberately designed to shift the contact area toward the CPU hotspot, which is particularly relevant for modern multi-die AMD CPUs (chiplet architectures on AM5) where the heat source is not centred on the IHS. Heat is drawn into a stack of 46 aluminium fins, each 0.4 mm thick, maximising surface area within the compact envelope. Airflow is handled by a single 100 mm × 25 mm P10 PWM fan. Running on a fluid dynamic bearing — a low-friction design that reduces mechanical noise — the fan operates between 200 and 2,300 rpm under PWM control. Below 5% PWM duty cycle, the fan stops entirely (0 rpm), allowing near-silent operation during light workloads. The fan draws 0.13 A at 12 V DC and connects via a standard 4-pin PWM header. The cooler ships with ARCTIC MX-6 thermal compound pre-applied to the base, so no separate paste application is required before the first installation. Mounting hardware in the box covers AMD AM5 and AM4 only; no Intel brackets are included, which ARCTIC states is a deliberate effort to reduce packaging waste. Operating ambient temperature range is specified at 0–40 °C. The cooler weighs 415 g (gross packaged weight 589 g). ARCTIC backs the Freezer 8A with a 6-year warranty. Verified Specifications: • Compatibility: AMD AM5, AM4 • Dimensions: 83 (L) × 108 (W) × 136 (H) mm | Weight: 415 g • Heatpipes: 2× Ø 6 mm copper, direct touch, offset arrangement • Fin stack: 46× 0.4 mm aluminium fins • Fan: 1× P10 PWM, 100 (L) × 100 (W) × 25 (H) mm • Fan speed: 200–2,300 rpm PWM (0 rpm below 5% PWM) • Bearing: Fluid Dynamic Bearing • Electrical: 0.13 A | 12 V DC | 4-pin connector • Thermal compound: MX-6 pre-applied • Operating ambient temperature: 0–40 °C • Warranty: 6 years • SKU: ACFRE00161A | EAN: 4895265000058
