ASRock B760M Pro-A WiFi M-ATX Motherboard

The ASRock B760M Pro-A WiFi 6E is a Micro-ATX form factor motherboard built on Intel's B760 chipset, designed for LGA1700 socket processors spanning 12th, 13th, and 14th Generation Intel Core CPUs. It offers a compelling combination of modern connectivity, reliable power delivery, and compact dimensions suited to mainstream desktop builds. Power delivery is handled by a 7+1+1 phase design using Dr.MOS integrated power stage technology, which consolidates driver and MOSFET components to deliver cleaner, more efficient power to the CPU under sustained workloads. The 6-layer PCB further contributes to signal integrity and thermal management, particularly relevant when running memory at elevated frequencies. Four DDR5 DIMM slots support dual-channel operation with a maximum capacity of 256 GB. Memory speeds can reach up to 7200 MT/s under overclocking profiles, with support for Intel XMP 3.0 for straightforward profile-based tuning. ASRock has also included a DDR5 protection circuit to reduce the risk of module damage during improper installation. Expansion is provided by one PCIe 5.0 x16 slot with a reinforced steel bracket for heavy graphics cards, and one PCIe 3.0 x16 slot running at x4 bandwidth. Storage connectivity includes four SATA3 ports and three Hyper M.2 slots, each capable of PCIe Gen 4 x4 speeds. Wireless connectivity is delivered via an Intel Killer Wi-Fi 6E (802.11ax) module covering 2.4 GHz, 5 GHz, and the 6 GHz band, paired with Bluetooth. Wired networking uses a Dragon 2.5 Gigabit LAN controller. Display outputs on the rear panel include one HDMI 2.1 port (up to 4K 60Hz) and one DisplayPort 1.4 with DSC (up to 8K 60Hz). Audio is handled by a Realtek ALC897 7.1-channel HD audio codec. Rear I/O includes one USB 3.2 Gen1 Type-C, three USB 3.2 Gen1 Type-A, two USB 2.0 ports, PS/2, and HD audio jacks. Internal headers add one front-panel USB 3.2 Gen1 Type-C (5 Gbps), two additional USB 3.2 Gen1 ports via header, and four USB 2.0 ports via headers. RGB enthusiasts will find one 12V RGB header and three 5V addressable RGB headers, compatible with ASRock Polychrome RGB Sync. A Thunderbolt AIC 5-pin connector supports optional ASRock Thunderbolt 4 expansion cards. Key Verified Specifications: - Socket: LGA1700 - Chipset: Intel B760 - CPU Compatibility: 12th, 13th, 14th Gen Intel Core - Form Factor: Micro-ATX - Memory: 4x DDR5, dual-channel, up to 256 GB, up to 7200+(OC), XMP 3.0 - Expansion: 1x PCIe 5.0 x16, 1x PCIe 3.0 x16 (x4 mode) - Storage: 4x SATA3, 3x M.2 (PCIe Gen4 x4) - Display Out: 1x HDMI 2.1 (4K 60Hz), 1x DisplayPort 1.4 (8K 60Hz w/DSC) - Networking: Intel Killer WiFi 6E 802.11ax + BT, Dragon 2.5G LAN - Audio: Realtek ALC897 7.1 CH HD - USB (Rear): 1x USB 3.2 Gen1 Type-C, 3x USB 3.2 Gen1 Type-A, 2x USB 2.0 - Warranty: 3 Years - Price: ₹12,650 (MRP ₹15,000)
