ASUS Dual GeForce RTX 5060 Ti 16GB Nvidia Graphic Card

The ASUS Dual GeForce RTX 5060 Ti 16GB (model DUAL-RTX5060TI-16G) brings NVIDIA’s Blackwell-generation GPU architecture to a compact, SFF-compatible package without compromising on thermal headroom or feature depth. At its core sits the GeForce RTX 5060 Ti silicon with 4608 CUDA cores, backed by 16 GB of fast GDDR7 memory running at 28 Gbps across a 128-bit interface — giving it a memory bandwidth profile well-suited to high-refresh 1080p and demanding 1440p workloads. Cooling is handled by two Axial-tech fans, each featuring a smaller hub that permits longer blade sweeps and a barrier ring to direct airflow downward through the heatsink fins. Dual-ball fan bearings replace the sleeve-bearing design found on entry-level cards, providing significantly extended operational longevity. ASUS’s 0dB Technology halts both fans entirely when GPU temperature drops below 50 °C and power draw is low, keeping the system silent during light or idle use. A vented backplate supplements airflow and helps shed heat away from the PCB during sustained loads. The entire cooler assembly is contained within a 2.5-slot footprint measuring 229 × 120 × 50 mm, making the card compatible with small-form-factor chassis that support PCIe cards of that thickness. Dual BIOS lets you toggle between Performance mode — which runs a more aggressive fan curve for lower core temperatures — and Quiet mode, which prioritises acoustic comfort at moderate thermal loads. Both profiles leave power target and core clocks unchanged; the default boost clock is 2572 MHz, rising to 2602 MHz in OC mode. Fine-grained control is available through the bundled ASUS GPU Tweak III software. ASUS Auto-Extreme Technology completes all PCB soldering in a single automated pass, reducing component thermal stress during manufacturing. On the display side, the card exposes one HDMI 2.1b port and three DisplayPort 2.1b ports, supporting up to four simultaneous displays at a digital maximum resolution of 7680 × 4320 (8K). HDCP 2.3 is supported. The card connects over PCI Express 5.0 and draws supplemental power through a single 8-pin connector; ASUS recommends a minimum 550 W system PSU. NVLink and CrossFire multi-GPU configurations are not supported. NVIDIA platform features enabled by the RTX 5060 Ti include fifth-generation Tensor Cores with FP4 support for DLSS 4 and AI workloads rated at 759 TOPS, fourth-generation Ray Tracing Cores, and the ninth-generation NVENC encoder for accelerated video exports in applications such as DaVinci Resolve and Adobe Premiere Pro. NVIDIA Broadcast, RTX Video Super Resolution, RTX Video HDR, and RTX Remix are also available through driver and software support. Verified Specifications: • GPU: NVIDIA GeForce RTX 5060 Ti | CUDA Cores: 4608 • Video Memory: 16 GB GDDR7 | Memory Speed: 28 Gbps | Memory Interface: 128-bit • Boost Clock: 2572 MHz (Default) / 2602 MHz (OC mode) • AI Performance: 759 TOPS | Bus: PCI Express 5.0 • Outputs: 1× HDMI 2.1b, 3× DisplayPort 2.1b | Max Displays: 4 | Max Resolution: 7680×4320 • Power Connector: 1× 8-pin | Recommended PSU: 550 W • Dimensions: 229 × 120 × 50 mm | Slot: 2.5 | SFF Ready: Yes • OpenGL: 4.6 | HDCP: 2.3 | Warranty: 3 Years
