Asus GT 1030 2GB Graphics Card
MPN GT1030-SL-2G-BRK · Brand ASUS
The ASUS GeForce GT 1030 2GB GDDR5 low-profile graphics card features fully passive cooling for silent HTPC builds, with HDMI 2.0b and DVI-D outputs, 384 CUDA cores, and support for DirectX 12 — all in a compact, no-power-connector design
Inclusive of GST · GST invoice available
Overview
The ASUS GeForce GT 1030 2GB GDDR5 Low Profile Graphics Card (model GT1030-SL-2G-BRK) is engineered for quiet, compact PC builds where silent operation and a small form factor are top priorities. Built on the NVIDIA Pascal architecture, it uses a fully passive heatsink design — no fan, no noise — making it an excellent match for home theatre PCs, multimedia workstations, and compact desktop upgrades that demand silence above all else. The card's 384 CUDA cores handle everyday computing, media playback, and light creative workloads with ease. With HDMI 2.0b and DVI-D outputs, you can connect up to two displays simultaneously and drive resolutions up to 4096 x 2160 at 60 Hz over HDMI. Support for DirectX 12 and OpenGL 4.5 keeps the card compatible with modern software and games that do not demand high-end rasterisation. ASUS builds the GT1030-SL-2G-BRK using its AUTO-EXTREME automated manufacturing process, which eliminates human contact during soldering for consistent quality. The GPU Tweak II utility lets you monitor and adjust clock speeds through an accessible interface; in its default Gaming Mode the GPU Boost clock runs at 1468 MHz (base 1228 MHz), while switching to OC Mode raises those figures to 1506 MHz boost and 1266 MHz base. The low-profile PCIe 3.0 x4 card ships with I/O port brackets to fit both standard and low-profile chassis without modification. It requires no external power connector and is rated for a recommended system PSU of 300 W, so it drops cleanly into most pre-built or compact systems. Key Verified Specifications: - GPU: NVIDIA GeForce GT 1030 (Pascal) - CUDA Cores: 384 - Video Memory: 2 GB GDDR5 - Memory Interface: 64-bit - Memory Clock: 6008 MHz effective - GPU Boost Clock (Gaming / OC): 1468 MHz / 1506 MHz - GPU Base Clock (Gaming / OC): 1228 MHz / 1266 MHz - Display Outputs: 1 x HDMI 2.0b, 1 x DVI-D - Max Resolution: 4096 x 2160 - Max Displays Supported: 2 - API Support: DirectX 12, OpenGL 4.5 - Bus Interface: PCI Express 3.0 - Power Connector: None required - Recommended PSU: 300 W - Form Factor: Low profile (brackets included) - Software: ASUS GPU Tweak II - Warranty: 3 Years
Datasheet
| Memory Type | GDDR5 |
|---|---|
| Warranty | 3 Years |
| Chipset | NVIDIA GEFORCE |
| Memory Size | 2 GB |
| GPU | GT 1030 |
| Memory Clock | 6008 MHz |
| Recommended PSU | 300W |
| Resolution | 4096 x 2160 |
| Model | GT1030-SL-2G-BRK |
| Ports | DVI-D, HDMI |
| Cooler | Passive |
| Note** | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only |
| Opengl | 4.5 |
| Directx | 12 |
| Pci Express | 3.0 |
| Engine Clock | OC Mode – GPU Boost Clock : 1506 MHz , GPU Base Clock : 1266 MHz Gaming Mode (Default) – GPU Boost Clock : 1468 MHz , GPU Base Clock : 1228 MHz |
| Memory Interface | 64-BIT |
| Max Display Support | 2 |
| GPU Core (Cuda Core) | 384 |
