Asus TUF Gaming GT502 ATX Mid Tower Case
MPN TUF-GAMING-GT502-BLACK · Brand ASUS · ATX, mATX, Mini-ITX
The ASUS TUF Gaming GT502 ATX mid-tower case features a dual-chamber chassis with independent CPU and GPU cooling zones, 360mm top radiator support, tempered glass front and side panels, and a USB 3.2 Gen 2 Type-C front port
Inclusive of GST · GST invoice available
Overview
The ASUS TUF Gaming GT502 is an ATX mid-tower PC case engineered around a dual-chamber chassis design that physically separates the CPU and GPU cooling zones. This split layout lets you configure independent airflow paths for each thermal zone, reducing heat cross-contamination between your processor and graphics card while keeping cable runs tidy inside the main chamber. The front and left side panels are constructed from tempered glass with a tactful tint, offering a clear view of your build interior without overwhelming glare. Side panels are tool-free and removable with a rear-mounted hidden button, making hardware swaps straightforward. A fully modular panel and mount system means most internal brackets and covers can be stripped away entirely, giving you maximum flexibility whether you are assembling a compact single-GPU rig or a fully loaded workstation. The rear chamber houses a 360mm hybrid bracket that can accept a radiator-and-fan combination or be reconfigured to mount up to three storage devices, giving the build room to grow. A vertical GPU mount is included in the box, allowing you to stand your graphics card on its edge for an aesthetically striking display, while a bundled support bracket addresses sag if you choose the conventional horizontal orientation. Front-panel connectivity is strong for its class: two USB 3.2 Gen 1 Type-A ports and one USB 3.2 Gen 2 Type-C port delivering up to 10 Gbps sit alongside a combined headphone and microphone jack and an LED control button. Two detachable woven carry straps rated for up to 30 kg make transporting a fully built system safer and more manageable. Verified Specifications: - Form Factor: ATX / Micro-ATX / Mini-ITX - Dimensions: 285 × 450 × 446 mm - Weight: 11 kg - Drive Bays: 4 × 2.5″/3.5″ combo - Expansion Slots: 8 + 3 vertical - Max CPU Cooler Height: 163 mm - Max GPU Length: 400 mm - Max PSU Length: 200 mm - Top Radiator Support: 120 / 140 / 240 / 280 / 360 mm - Rear Radiator Support: 120 mm - Top Fan Support: 3 × 120 mm or 2 × 140 mm - Rear Fan Support: 1 × 120 mm - Front I/O: 2 × USB 3.2 Gen 1, 1 × USB 3.2 Gen 2 Type-C, 1 × audio combo - Tempered Glass: Front and left side panels - Removable Dust Filters: Top, bottom, right - Warranty: 1 Year
Datasheet
| Warranty | 1 Year |
|---|---|
| Form Factor | ATX, mATX, Mini-ITX |
| Color | Black |
| Weight | 11Kg |
| Material | Tempered Glass |
| Case Size | Mid Tower |
| Dimensions | 285 x 450 x 446 mm |
| Drive Bays | 4 x 2.5"/3.5" Combo Bay |
| Cabinet Size | MID-TOWER |
| Dust Filters | Top,Bottom,Right |
| Max 2.5" SSD | 4 |
| Max 3.5" HDD | 4 |
| Product Name | TUF Gaming GT502 |
| Front I/O Port | 1 x headphone / Microphone 2 x USB 3.2 Gen1 1 x USB 3.2 Gen2 Type C LED Control Button |
| Max GPU Length | 400mm |
| Max Psu Length | 200mm |
| Tempered Glass | Front Side Left Side |
| Expansion Slots | 8 + 3 |
| Front I/O Panel | headphone,Microphone,USB 3.2 Gen1,USB 3.2 Gen 2×2 Type C,LED Control Button |
| Max Fan Support | 4 |
| Radiator Support | 360mm,280mm,240mm,140mm,120mm |
| Maximum GPU Length | 400 mm |
| Maximum Psu Length | 200 mm |
| Motherboard Support | ATX Micro-ATX Mini-ITX |
| Cooling Support (Top) | 3 x 120 mm 2 x 140 mm |
| Max CPU Cooler Height | 163mm |
| Cooling Support (Rear) | 1 x 120 mm |
| Radiator Support (Top) | 120 mm 140 mm 240 mm 280 mm 360 mm |
| Removable Dust Filters | Top Bottom Right |
| Radiator Support (Rear) | 120 mm |
| Maximum CPU Cooler Height | 163 mm |
