Cooler Master HAF 700 EVO ARGB Grey E-ATX Full Tower Case
MPN H700E-IGNN-S00 · Brand COOLER MASTER · E-ATX, ATX, mATX, Mini-ITX
The Cooler Master HAF 700 EVO ARGB (H700E-IGNN-S00) is an E-ATX full tower case with 7 pre-installed fans, IRIS LCD, PCIe 4.0 vertical GPU support, and radiator compatibility up to 420mm — built for demanding custom and liquid-cooled rigs
Inclusive of GST · GST invoice available
Overview
The Cooler Master HAF 700 EVO ARGB (model H700E-IGNN-S00) is a full tower PC chassis engineered for high-performance builds that demand exceptional thermal headroom and hardware flexibility. Its multi-chamber layout separates heat-sensitive components from the rest, concentrating airflow where it matters most. The case ships with seven pre-installed fans: two exclusive 200mm SickleFlow PWM Performance Edition fans at the front and three 120/140mm fans at the bottom, complemented by two 120mm SickleFlow PWM ARGB fans at the rear — all managed through an integrated 7x PWM and 5x ARGB hub for simplified cable routing and lighting control. The HAF 700 EVO accommodates motherboards from Mini-ITX all the way up to SSI-EEB, making it one of the most board-compatible enclosures in its class. Graphics cards up to 490mm in length can be mounted either horizontally or vertically, with an included PCIe 4.0 riser cable and a tool-less clamping mechanism that removes the need for a screwdriver during GPU installation or upgrade. Radiator support is equally comprehensive: up to a 420mm unit at the front, bottom, or via dual 360mm radiators at the top, and up to 480mm on the side panel — accommodating virtually any custom liquid cooling loop. The IRIS LCD assistant displays real-time system and game statistics or custom media, and integrates with Cooler Master's MasterPlus+ software. ARGB Gen 2 technology enables per-LED lighting customisation across compatible components. Thick tempered glass intake blades on the front panel deliver an edge-lit ARGB effect while preserving mesh-level airflow. The removable top panel provides unobstructed access to radiators and fans even in complex custom-loop builds. Storage expandability is broad, with up to 12 drive positions across 2.5-inch and 3.5-inch bays. The tool-less PSU mount, swivelling HDD cage, and repositionable multifunction brackets for SSDs, HDDs, pumps, and reservoirs further simplify assembly and future upgrades. Verified Specifications: - Model: H700E-IGNN-S00 - Form Factor: Full Tower - Exterior Colour: Titanium Grey - Motherboard Support: Mini-ITX, Micro-ATX, ATX, E-ATX, SSI-CEB, SSI-EEB - Dimensions (Body): 556 x 279 x 540 mm; 666 x 291 x 626 mm incl. protrusions - Pre-installed Fans: 7 total (2x 200mm front, 3x 120/140mm bottom, 2x 120mm rear) - Max Fan Support: 18 fans total - Max GPU Length: 490mm - Max CPU Cooler Height: 166mm - Max PSU Length: 200mm - Radiator Support: Up to 420/360mm front, 420/360mm bottom, 480/420mm side, 2x360mm/1x420mm top, 240mm rear - I/O: 1x USB 3.2 Gen 2 Type-C, 4x USB 3.2 Gen 1 (Type-A), 3.5mm audio + mic - Drive Bays: 12x 2.5-inch, 12x 3.5-inch (combo) - Expansion Slots: 8 - Cable Routing Space: 90–101mm behind motherboard tray - Dust Filters: Front, bottom, side - Exterior Materials: Mesh, steel, plastic; left side panel: tempered glass, steel - Warranty: 2 Years
Datasheet
| Warranty | 2 Years |
|---|---|
| Form Factor | E-ATX, ATX, mATX, Mini-ITX |
| Color | Black |
| Size | Full Tower |
| Series | HAF Series |
| Note*** | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only |
| Material | Mesh, Steel, Plastic, Tempered Glass |
| Cabinet Size | FULL-TOWER |
| Dust Filters | Front, Bottom, Side |
| Max 2.5" SSD | 12 |
| Max 3.5" HDD | 12 |
| Model | H700E-IGNN-S00 |
| Special Note | For regular 30mm thick radiators, for thicker please reference compatibility sheet |
| Exterior Color | Titanium Grey |
| Max GPU Length | 490mm |
| Max Psu Length | 200mm |
| 2.5" Drive Bays | 12 |
| Clearance - Gfx | 490mm / 19.29 inch |
| Clearance - Psu | 200mm / 7.87 inch |
| Expansion Slots | 8 |
| Front I/O Panel | USB 3.2, USB Type C |
| Max Fan Support | 18 |
| Radiator Support | 420mm,360mm,280mm,240mm,140mm,120mm |
| I/O Panel - Other | 1x LED Controller A1 (ARGB Gen 2), 1x ARGB/PWM Hub |
| Fan Support - Side | 4x 120mm / 3x 140mm |
| Pre Installed Fans | 7 |
| Motherboard Support | Mini ITX, Micro ATX, ATX, E-ATX, SSI CEB, SSI EEB |
| Materials - Exterior | Mesh, Steel, Plastic |
| Power Supply Support | Bottom Mount, ATX |
| I/O Panel - USB Ports | 1x USB 3.2 Gen 2 Type C, 4x USB 3.2 Gen 1 (3.0) |
| Max CPU Cooler Height | 166mm |
| Clearance - CPU Cooler | 166mm / 6.53 inch |
| Dimensions (L X W X H) | 556 x 279 x 540 mm (Body Size), 666 x 291 x 626 mm (incl. Protrusions) |
| Radiator Support - Top | Up to 2x 360mm / 1x 420mm |
| Radiator Support - Rear | Up to 240mm |
| Radiator Support - Side | Up to 480/420mm |
| Radiator Support - Front | Up to 420/360mm |
| Pre-Installed Fans - Rear | 2x SickleFlow PWM ARGB 120mm |
| Radiator Support - Bottom | Up to 420/360mm |
| I/O Panel - Audio In / Out | 1x 3.5mm 4 Poles Audio Jack, 1x 3.5mm Mic Jack |
| Pre-Installed Fans - Front | 2x SickleFlow PWM Performance Ed. 200mm |
| Materials - Left Side Panel | Tempered Glass, Steel |
| Pre-Installed Fans - Bottom | 3x 120/140mm |
| 2.5" / 3.5" Drive Bays (Combo) | 12 |
| Additional Included Accessories | Universal Graphics Card Holder Kit V2 |
| Cable Routing - Behind Motherboard Tray | 90-101mm |
