Cooler Master MasterBox TD500 Mesh V2 ARGB White E-ATX Mid Tower Case

The Cooler Master MasterBox TD500 Mesh V2 in white is a mid-tower ATX chassis built around a polygonal FineMesh front panel that delivers a combination of high airflow and front-panel dust filtration. The three-dimensional contoured mesh design gives the case its distinctive geometric appearance while channelling air efficiently to the components inside. Three CF120 ARGB 120mm fans come pre-installed at the front, providing airflow from the moment the system is assembled. An included ARGB and fan hub controller lets you manage lighting independently of motherboard software and adds four extra fan headers for expansion. The tool-free crystalline tempered glass side panel swings open without screws, giving quick access to the internals, and the fully removable top panel simplifies radiator mounting during the build process. Cooling flexibility is a defining strength of the TD500 Mesh V2. The front and top positions each accept radiators up to 360mm, with the top position supporting a recommended maximum thickness of 55mm. Up to seven 120mm fans can be fitted across the front (up to three 120mm or two 140mm), top (up to three 120mm or two 140mm), and rear (one 120mm) positions, keeping even thermally demanding configurations within comfortable operating ranges. The I/O panel on the top of the case includes two USB 3.2 Gen 1 Type-A ports, one USB 3.2 Gen 2 Type-C port, and a combined audio jack. The PSU shroud features a removable cover so builders can choose to display or conceal the power supply. Cable management space behind the motherboard tray measures 19mm. Motherboard compatibility spans Mini-ITX, Micro-ATX, ATX, SSI CEB, and E-ATX formats; E-ATX boards are supported up to 12 inches by 10.7 inches, though this may affect cable routing. Storage provisions include two 3.5-inch drive bays and three 2.5-inch drive bays. Seven expansion slots accommodate multi-slot GPU configurations, with a verified graphics card clearance of 410mm and CPU cooler clearance of 165mm. Dust filters are present at the front, top, and bottom. Key Specifications: - Model: TD500V2-WGNN-S00 - Colour: White - Form Factor: Mid Tower - Dimensions (incl. protrusions): 499 x 210 x 500 mm - Volume: 50 L (excl. protrusions) - Motherboard Support: Mini-ITX, Micro-ATX, ATX, SSI CEB, E-ATX (up to 12" x 10.7") - Pre-installed Fans: 3x 120mm CF120 ARGB (front) - Fan Support: Up to 7x 120mm total - Radiator Support: Up to 360mm front and top; 120mm rear - GPU Clearance: 410mm - CPU Cooler Clearance: 165mm - I/O: 2x USB 3.2 Gen 1, 1x USB 3.2 Gen 2 Type-C, 1x Audio Jack - Drive Bays: 2x 3.5", 3x 2.5" - Expansion Slots: 7 - Side Panel: Tempered Glass (tool-free) - Exterior Material: Steel, Mesh, Plastic - Dust Filters: Front, Top, Bottom - PSU: Bottom-mount ATX, up to 200mm (recommended up to 170mm) - Warranty: 2 Years
