Cooler Master MasterFrame 360 Panorama ATX Mid Tower Case

The Cooler Master MasterFrame 360 Panorama is an open-frame ATX mid-tower case built around the FreeForm 2.0 design philosophy, placing your hardware at the centre of attention rather than hiding it behind closed panels. Its aluminium exo-structure and a dedicated central cable management chamber combine to deliver clean, clutter-free builds that showcase every component from every angle. At the heart of the MasterFrame 360's appeal is its panoramic display concept. The open-frame chassis removes the visual barriers of a conventional enclosure, giving you space to arrange figures, collectibles, or creative accessories up to 328 × 290 × 110 mm in front of the board. A front-facing LCD completes the effect by reflecting your build from all 360 degrees, turning your PC into a personalised display. Cooling headroom is exceptional. The top and bottom panels each accept fans ranging from 120 mm all the way to 200 mm, accommodating up to six 120 mm fans per panel for a maximum of twelve 120 mm fans in total. Both positions also support radiators up to 360 mm with up to 75 mm thickness clearance, making this case suitable for the most demanding custom liquid cooling loops. Component compatibility is equally broad. GPU clearance extends to 430 mm, covering current flagship cards, while PSU length support reaches 210 mm. Motherboard support spans Mini-ITX, Micro-ATX, standard ATX, and BTF (back-connect) layouts within the ATX form factor, keeping options open for next-generation board designs. CPU cooler height clearance is 145 mm. Included in the box is a PCIe 5.0 riser cable that enables vertical GPU mounting out of the box, pairing next-generation bandwidth with an elevated visual presentation. Two pre-installed ARGB spotlights add accent lighting, while a pair of integrated USB 4.0 Gen 2 Type-C 20 Gbps and USB 3.2 Gen 1 Type-A 5 Gbps ports plus a 3.5 mm headset jack are available on the front I/O panel for convenient connectivity. Verified Specifications: • Dimensions (L × W × H, incl. protrusions): 549 × 291 × 581 mm • Dimensions (excl. protrusions): 511 × 291 × 581 mm • Volume: 86 L (without panel/protrusions/feet); 93 L (with) • Form factor support: Mini-ITX, Micro-ATX, ATX (incl. BTF) • Fan support – top: 6× 120 mm / 2× 140 mm / 2× 180 mm / 2× 200 mm • Fan support – bottom: 6× 120 mm / 2× 140 mm / 2× 180 mm / 2× 200 mm • Total max fan support: 12 • Radiator support (top & bottom): 120 / 140 / 240 / 280 / 360 mm (max 75 mm thick) • Max GPU length: 430 mm • Max PSU length: 210 mm • Max CPU cooler height: 145 mm • Drive bays: 1× 3.5" HDD or 2× 2.5" SSD • Storage capacity (attributes): up to 2× 3.5" HDD / 4× 2.5" SSD • Expansion slots: 3.5 (vertical riser layout) • Front I/O: USB 4.0 Gen 2 Type-C 20 Gbps, USB 3.2 Gen 1 Type-A 5 Gbps, 3.5 mm headset jack • Included accessories: 1× PCIe 5.0 riser cable, 2× ARGB spotlight • Material: SGCC steel + tempered glass • Colour: Black • Warranty: 2 years • SKU: MF360-KINN-S00
