Cooler Master MasterLiquid Atmos II LCD 360mm ARGB CPU Liquid Cooler

The Cooler Master MasterLiquid Atmos II LCD 360mm ARGB AIO CPU Liquid Cooler (SKU: MLX-D36M-A25SZ-L1) delivers a compelling blend of high-capacity thermal performance and personalised visual feedback, making it a strong choice for builders running modern Intel and AMD platforms. At the heart of the cooler sits a patented dual-chamber pump design that increases water pressure and focuses flow directly onto the CPU hot spot. The pump housing is constructed from PPS and fiberglass, providing industrial-grade rigidity and heat resistance. Cooler Master subjects the assembly to rigorous endurance testing — 3,000 hours at 70 °C and 12 hours at 120 °C — to underpin long-term reliability. The standout feature of the Atmos II LCD is its 2.1-inch circular IPS-style LCD display mounted on the pump head. Measuring 53.3 mm in diameter with a 480 × 480 px resolution and 300 cd/m² luminance, the panel connects to the motherboard via a USB Type-C to 9-pin header cable and refreshes at 60 Hz, allowing real-time monitoring data or custom images to be displayed without third-party hardware. Three pre-installed 120 mm SickleFlow Edge ARGB fans deliver a combined airflow of 190 CFM (322.8 m³/h) and generate up to 3.61 mmH₂O of static pressure against the 360 mm aluminium radiator. Each fan uses a Loop Dynamic Bearing and connects via a 7-pin PWM + ARGB header, allowing both speed and lighting to be managed from the motherboard. The pump spins up to 3,400 ± 300 RPM, draws just 3.84 W, and carries an MTTF rating of over 210,000 hours. Socket compatibility spans the current mainstream Intel and AMD ecosystems. Cooler Master also includes offset mounting brackets specifically designed for LGA 1851, which position the cold plate to target the shifted hot spot on Intel Core Ultra processors and yield a claimed 4 °C improvement in heat extraction from the CPU centre. — Verified Specifications — Radiator material: Aluminium | Radiator dimensions: 394 × 119.2 × 27 mm | Fan size: 3 × 120 mm | Fan airflow: 190 CFM / 322.8 m³/h | Fan static pressure: 3.61 mmH₂O | Fan noise (max): 38.5 dB(A) | Fan connector: 7-pin PWM + ARGB | Pump speed: 3,400 ± 300 RPM | Pump noise (max): 25 dBA | Pump MTTF: >210,000 hours | Pump power: 3.84 W | Pump connector: 3-pin ARGB + 4-pin PWM | Tube length: 400 mm | LCD size: 2.1 in / 53.3 mm diameter | LCD resolution: 480 × 480 px | LCD luminance: 300 cd/m² | LCD refresh rate: 60 Hz | LCD power: 1.5 W | LCD connector: USB Type-C to 9-pin MB header | Socket support — Intel: LGA 1851 / 1700 / 1200 / 1156 / 1155 / 1151 / 1150 | AMD: AM5 / AM4 | Warranty: 6 years
