Cooler Master MasterLiquid Core NEX Digital 360 White CPU Liquid Cooler
MPN MLX-D36M-A18PW-RD · Brand COOLER MASTER
Cooler Master MasterLiquid Core NEX Digital 360mm White AIO cooler featuring a hexagonal LED digital display, patented dual-chamber pump at 3,200 RPM, three 120mm ARGB fans, and broad Intel LGA 1851/1700 and AMD AM5/AM4 socket compatibility
Inclusive of GST · GST invoice available
Overview
The Cooler Master MasterLiquid Core NEX Digital 360 (White) is a 360mm all-in-one liquid CPU cooler engineered for PC builders, gamers, and content creators who want reliable thermal performance paired with a distinctive visual identity. Its most immediately recognisable feature is the pump head's hexagonal LED digital display, which presents real-time system data — CPU usage, temperatures, fan speeds, and pump speeds — directly on the cooler itself. Display parameters are configurable through Cooler Master's MasterCTRL software, giving you full control over what information appears and how it is presented. At the heart of the cooler is Cooler Master's patented dual-chamber pump design. The two-chamber configuration increases internal water pressure and focuses coolant flow directly at the CPU heat-spreader hot spot, improving heat transfer efficiency over single-chamber alternatives. The pump operates at up to 3,200 RPM (±10%) and connects via a 4-pin PWM connector for speed control, while a separate 3-pin ARGB connector drives the addressable RGB lighting. Three 120mm PWM fans mount to the aluminium 360mm radiator, which measures 394 × 119.6 × 27.2 mm. The 400mm tubing length is intentionally sized to accommodate a wide range of case orientations — top, front, or side — without straining the hoses. Fans are pre-installed, thermal paste comes pre-applied, and mounting brackets for all supported sockets are pre-assembled, reducing installation time significantly. Socket compatibility covers the current mainstream Intel and AMD platforms as well as several legacy sockets, making this cooler suitable for new builds and upgrades alike. Verifiable specifications: • Radiator dimensions: 394 × 119.6 × 27.2 mm • Pump dimensions: 83.6 × 78.5 × 68.6 mm • Pump speed: 3,200 RPM ±10% • Pump connector: 4-pin PWM + 3-pin ARGB • Fan size: 3 × 120 mm (PWM) • Tubing length: 400 mm • Radiator material: Aluminium • Digital panel type: LED digital display • Intel socket support: LGA 1851, 1700, 1200, 1156, 1155, 1151, 1150 • AMD socket support: AM5, AM4 • Supported CPUs: Intel Core i3/i5/i7/i9, Core Ultra 5/7/9; AMD Ryzen 3/5/7/9 • Warranty: 5 years • SKU / Product number: MLX-D36M-A18PW-RD
Datasheet
| Warranty | 5 Years |
|---|---|
| Note*** | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only |
| Fan Size | 120 mm |
| Cooling Type | LIQUID AIO COOLER |
| Radiator Size | 360 mm |
| Pwm Controller | YES |
| Socket Support | LGA1700,LGA1851,LGA1200,LGA1156,LGA1155,LGA1151,LGA1150,AM5,AM4 |
| Supported Cooler CPU Wise | intel i3,intel i5,intel i7,intel i9,Core ultra 5,Core ultra 7,Core ultra 9,AMD Ryzen 3,AMD Ryzen 5,AMD Ryzen 7,AMD Ryzen 9 |
