COOLER MASTER MasterLiquid PL360 Flux Edition ARGB 360mm CPU Liquid Cooler (White)
MPN COOLER-MASTER-MASTERLIQUID-PL360-FLUX-ARGB-WHITE · Brand Cooler Master
Features of Cooler Master MasterLiquid PL360 Flux Edition ARGB 360mm CPU Liquid Cooler (White) Cooler Master MasterLiquid PL360 Flux Edition ARGB 360mm CPU Liquid Cooler (White) features with Dual Loop ARGB Pump Lighting, Dual Chamber pump delivers the perfect balance of water flow and pressure for impressive cooling. Performance Dual Chamber Superior Performance Ratio Ultimate Heat Exchange Slim & Sleek Radiator PL-Flux specific fans Dual Loop ARGB Pump Lighting Cooling Uncompromised Cooler
Inclusive of GST · GST invoice available
Overview
Features of Cooler Master MasterLiquid PL360 Flux Edition ARGB 360mm CPU Liquid Cooler (White)
Cooler Master MasterLiquid PL360 Flux Edition ARGB 360mm CPU Liquid Cooler (White) features with Dual Loop ARGB Pump Lighting, Dual Chamber pump delivers the perfect balance of water flow and pressure for impressive cooling.
- Performance Dual Chamber
- Superior Performance Ratio
- Ultimate Heat Exchange
- Slim & Sleek Radiator
- PL-Flux specific fans
- Dual Loop ARGB Pump Lighting
Cooling Uncompromised
Cooler Master’s Flux is the new embodiment of enhanced performance cooling. The dual chamber pump has further honed flow and pressure to target hot spots for rapid and precise heat dissipation.
Performance Dual Chamber
Cooler Master MasterLiquid PL360 Flux Edition ARGB 360mm CPU Liquid Cooler (White) comes with a new Compact Performance Dual Chamber pump delivers the perfect balance of water flow and pressure for impressive cooling.
Superior Performance Ratio
Precision engineered ultra-thin spaded fins maximizes microchannels accurately targets heat spots. Enlarged copper base surface area optimized with ideal base thickness accelerates heat transfer.
Ultimate Heat Exchange
Cooler Master MasterLiquid PL360 Flux Edition ARGB 360mm CPU Liquid Cooler (White) has a high speed motor utilizing a ceramic bearing impeller forces balanced water flow to and from the radiator for ultimate efficiency of heat exchange.
Slim & Sleek Radiator
Cooler Master MasterLiquid PL360 Flux Edition ARGB 360mm CPU Liquid Cooler (White) features a low profile radiator with superior fin density coupled with performance fans dissipates heat rapidly.
PL-Flux Specific Fans
Inter-conneting air balance fan blades increased sturdiness and stability operating steadily at high speed. Angled inner rim of fan frame increasing intake of air, at the same time gap between from and blades creating greater air pressure.
Dual Loop ARGB Pump Lighting
Addressable Gen 2 RGB ready for independent implemented customization
Specifications of Cooler Master MasterLiquid PL360 Flux Edition ARGB 360mm CPU Liquid Cooler (White):
| Product Number | Cooler Master MasterLiquid PL360 Flux Edition ARGB 360mm CPU Liquid Cooler (White) (MLY-D36M-A23PZ-RW) |
| Exterior Color | White |
| CPU Socket | LGA1700, LGA1200, LGA2066, LGA2011-v3, LGA2011, LGA1151, LGA1150, LGA1155, LGA1156, AM5, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1, TR4 |
| Radiator Material | Aluminum |
| Radiator Dimensions | 394 x 119.6 x 27.2 mm / 15.5 x 4.7 x 1.07 inch |
| Pump Dimensions | 89 x 75 x 40 mm / 3.5 x 2.95 x 1.57 inch |
| Pump MTTF | >210,000 Hours |
| Pump Noise Level | 15 dBA (Max) |
| Pump Connector | 4-Pin (PWM) |
| Pump Rated Voltage | 12 VDC |
| Pump Power Consumption | 6W |
| Fan Dimensions (L x W x H) | 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch |
| Fan Quantity | 3 PCS |
| Fan LED Type | Addressable Gen 2 RGB |
| Fan Speed | 0-2300 RPM ± 10% |
| Fan Airflow | 72.37 CFM (Max) |
| Fan Noise Level | 32 dBA (Max) |
| Fan Pressure | 2.96 mmH₂O (Max) |
| Fan Bearing Type | Oil Reflow Bearing System |
| Fan MTTF | >160,000 Hours |
| Fan Power Connector | 4-Pin (PWM) |
| Fan Rated Voltage | 12VDC |
| Fan Rated Current | 0.15A |
| Fan Safety Current | 0.3A |
| Series | MasterLiquid Pro |
| Cooler Type | Liquid Cooler |
| Radiator Size | 360 |
| Warranty | 5 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
Datasheet
| Warranty | 5 Years |
|---|---|
| Socket | AM2, AM2+, AM3, AM3+, AM4, AM5, FM1, FM2, FM2+, LGA1150, LGA1151, LGA1155, LGA1156, LGA1200, LGA1700, LGA2011, LGA2066 |
| Series | MasterLiquid Pro |
| Fan Mttf | >160,000 Hours |
| Fan Speed | 0-2300 RPM ± 10% |
| Pump Mttf | >210,000 Hours |
| Cooler Type | Liquid Cooler |
| Fan Airflow | 72.37 CFM (Max) |
| Fan Led Type | Addressable Gen 2 RGB |
| Fan Pressure | 2.96 mmH₂O (Max) |
| Fan Quantity | 3 PCS |
| Radiator Size | 360 |
| Exterior Color | White |
| Product Number | Cooler Master MasterLiquid PL360 Flux Edition ARGB 360mm CPU Liquid Cooler (White) (MLY-D36M-A23PZ-RW) |
| Pump Connector | 4-Pin (PWM) |
| Fan Noise Level | 32 dBA (Max) |
| Pump Dimensions | 89 x 75 x 40 mm / 3.5 x 2.95 x 1.57 inch |
| Fan Bearing Type | Oil Reflow Bearing System |
| Pump Noise Level | 15 dBA (Max) |
| Fan Rated Current | 0.15A |
| Fan Rated Voltage | 12VDC |
| Radiator Material | Aluminum |
| Fan Safety Current | 0.3A |
| Pump Rated Voltage | 12 VDC |
| Fan Power Connector | 4-Pin (PWM) |
| Radiator Dimensions | 394 x 119.6 x 27.2 mm / 15.5 x 4.7 x 1.07 inch |
| Pump Power Consumption | 6W |
| Fan Dimensions (L X W X H) | 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch |
