COOLER MASTER MWE 750W 80+ White Non Modular ATX 2.0 Power Supply

The Cooler Master MWE 750W 80+ White is a non-modular ATX power supply designed to deliver dependable, consistent power to mainstream desktop builds. Rated at 750 watts continuous output, it carries an 80 PLUS Standard 230V EU certification, meaning it operates at a typical efficiency of 85% — converting more power from the wall and wasting less as heat. This makes it a practical choice for mid-range gaming rigs and productivity workstations that need steady, regulated power without unnecessary overhead. A single 12V rail topology ensures every connected component draws from one unified power source, reducing the risk of load imbalance across different parts of your system. The DC-to-DC LLC converter design handles the step-down of that 12V supply to the 3.3V and 5V levels that your storage drives, fans, and peripheral controllers require, doing so with low ripple noise and consistent voltage delivery. Cooling is handled by a 120mm Hydrodynamic Bearing (HDB) fan. Unlike sleeve-bearing fans, HDB fans use a thin film of oil to reduce friction between the shaft and bearing, which results in quieter operation and a longer service life. The fan is thermally controlled, spinning up only as internal temperatures demand — measuring just 11.12 dBA at 20% load for near-silent operation during light workloads, rising to 20.3 dBA at 50% load and 39.5 dBA at full load. The MWE 750W White ships with a comprehensive cable set to support a wide range of component configurations: one ATX 24-pin connector, one EPS 4+4-pin and one EPS 8-pin CPU power connector, four PCIe 6+2-pin connectors for GPU power, six SATA connectors, and three peripheral 4-pin connectors. Its compact 140 × 150 × 86 mm chassis fits standard ATX cases with ease. Protection circuits include over-voltage protection (OVP), over-power protection (OPP), short-circuit protection (SCP), under-voltage protection (UVP), and over-temperature protection (OTP), providing a safety net for your connected hardware. The unit meets ErP 2014 Lot 3 energy regulations and holds certifications including CCC, CE, TUV-RH, EAC, RCM, cTUVus, FCC, BSMI, KC, and CB. Verified Specifications: — Model: MPE-7501-ACABW-IN — Wattage: 750W (series covers 500–750W) — 80 PLUS Rating: Standard 230V EU — ATX Version: ATX 12V Ver. 2.52 — PFC: Active — Input Voltage: 200–240 Vac — Input Current: 6A — Input Frequency: 50–60 Hz — Fan: 120mm HDB, max 2400 RPM — Noise: 11.12 dBA (20%), 20.3 dBA (50%), 39.5 dBA (100%) — Efficiency: 85% typical — MTBF: >100,000 hours — Protections: OVP, OPP, SCP, UVP, OTP — Operating Temperature: up to 40°C — Hold-up Time: >14ms at full load @ 230 Vac — Dimensions: 140(L) × 150(W) × 86(H) mm — Warranty: 5 years
