Cooler Master Ncore 100 Max Dark Grey M-ITX Mini Tower Case

The Cooler Master Ncore 100 Max in Dark Grey is a feature-packed M-ITX mini tower that eliminates the usual small-form-factor sourcing headache by bundling everything you need into a single box. Unlike bare chassis, it ships with a V SFX Gold 850W ATX 3.0 power supply, a 120mm radiator AIO cooling solution with a custom PWM fan spinning up to 2400 RPM, and a 240mm PCIe 4.0 x16 riser cable — so your GPU can be mounted vertically right out of the box without any additional purchases. The exterior combines steel, plastic, and aluminium panels, with aluminium side panels giving the chassis a premium feel while keeping weight manageable. In Normal mode the case measures 155 mm × 212 mm × 481 mm (including protrusions) with an internal volume of just 15.80 litres, making it genuinely portable. Switching to Expansion mode widens the footprint to 172 mm × 212 mm × 481 mm and grows the volume to 17.54 litres, unlocking support for up to 3.9-slot-thick discrete GPUs with a maximum card length of 357 mm. Graphics card clearance is a highlight: Normal mode accommodates cards up to 337 mm long and 62 mm wide at a 3.0-slot thickness, while Expansion mode stretches that to 357 mm × 79 mm at 3.9 slots — measurements that include space for the GPU power connector. A rear 120mm Cooler Master SickleFlow PWM fan (max. 1800 RPM) provides additional exhaust, and dust filters on the side panels help keep the internals clean. Front I/O is well-equipped with two USB 3.2 Gen1 Type-A ports, one USB 3.2 Gen2×2 Type-C port, and a 3.5 mm audio combo jack. Verified Specifications: - Model: NCORE 100 MAX | SKU: NR100-MNNN85-SL0 - Form factor: M-ITX (Mini Tower) - Exterior materials: Steel, Plastic, Aluminium; Side panel: Aluminium - Dimensions (Normal, incl. protrusions): 155 mm × 212 mm × 481 mm - Dimensions (Expansion, incl. protrusions): 172 mm × 212 mm × 481 mm - Volume: 15.80 L (Normal) / 17.54 L (Expansion) - Motherboard support: ITX only - Expansion slots: 3× PCIe slot mounting - GPU clearance: 337 mm × 62 mm × 180 mm (Normal, 3.0-slot) / 357 mm × 79 mm × 180 mm (Expansion, 3.9-slot) - CPU cooler clearance: 48 mm - RAM clearance: 48 mm - PSU support: SFX (max. 100 mm) - Included PSU: V SFX Gold 850W ATX 3.0 - Included AIO: 120mm radiator (38 mm thick), custom PWM fan (max. 2400 RPM) - Included riser: 240mm PCIe 4.0 x16 - Pre-installed fan: 120mm SickleFlow PWM rear exhaust (max. 1800 RPM) - Drive bays: 1× 2.5" SSD - I/O panel: 2× USB 3.2 Gen1 Type-A, 1× USB 3.2 Gen2×2 Type-C, 1× 3.5 mm audio combo - Cable routing space (behind MB tray): 11 mm - Dust filters: Side panels - Radiator support: 120 mm - Colour: Dark Grey - Warranty: 2 years (case), 2 years (thermal solution), 10 years (power delivery)
