COOLER MASTER V650 SFX 80+ Gold Fully Modular Power Supply (650 W)

The Cooler Master V650 SFX (model MPY-6501-SFHAGV) is a 650-watt fully modular power supply built to the SFX form factor, measuring a compact 100 x 125 x 63.5 mm. It carries an 80 PLUS Gold efficiency certification and achieves 90% efficiency at typical load, which helps reduce heat output and keeps operating costs lower compared to lower-rated units. Designed with mini-ITX builders in mind, the V650 SFX ships with an SFX-to-ATX adapter bracket, so it can be installed in standard ATX and E-ATX cases as well, giving builders flexibility regardless of chassis size. All cables are fully detachable, meaning you connect only the leads your system actually needs. This approach simplifies routing in tight enclosures and supports cleaner airflow. Cooling is handled by a 92mm Fluid Dynamic Bearing (FDB) fan. The unit also supports a semi-fanless operating mode at lighter loads, reducing audible noise during everyday tasks. The fan and overall thermal design are rated to operate continuously between 0°C and 50°C. The V650 SFX includes a comprehensive set of connectors: one ATX 24-pin, one EPS 4+4-pin, one EPS 8-pin, four PCIe 6+2-pin, eight SATA, and four peripheral 4-pin. Active Power Factor Correction (Active PFC) is built in, and the unit accepts a universal input voltage range of 90–240 Vac at 47–63 Hz, making it compatible with Indian mains as well as international power standards. Protection circuits cover over-voltage (OVP), over-power (OPP), short-circuit (SCP), over-current (OCP), under-voltage (UVP), and over-temperature (OTP). The declared MTBF exceeds 100,000 hours, and the unit complies with ErP 2014 Lot 3 standby-power requirements. Regulatory certifications include CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, and CB. Verified Specifications: – Model: MPY-6501-SFHAGV – Wattage: 650 W – Form Factor: SFX (SFX-to-ATX bracket included) – Dimensions (L x W x H): 100 x 125 x 63.5 mm – Efficiency: 80 PLUS Gold / 90% at typical load – Fan: 92mm FDB bearing – Modular: Fully modular – Input Voltage: 90–240 Vac – Input Frequency: 47–63 Hz – Protections: OVP, OPP, SCP, OCP, UVP, OTP – MTBF: >100,000 hours – Hold-Up Time: 16 ms – ATX Version: ATX 12V V3.42 – Warranty: 10 years – PCIe 6+2-pin connectors: 4 – SATA connectors: 8
