Cougar MX230 RGB E-ATX Mid Tower Case

Features: All-metal front mesh panel doubles as dust filter. 3 x 120mm ARGB front fans and 1 x 120mm ARGB rear fan preinstalled. Porous PSU shroud seats 3 x 120mm fans, creating a true vertical intake path. Right-offset PSU cabin maximizes airflow space. Perforated base slopes increase intake surface area. Top filter rimmed with solid borders for a more refined look and feel. Supports 360mm AIO cooling up top and a maximum fan capacity of 10. Equipped with USB 3.2 Gen 2 2×1 Type-C (10Gbps) x 1 and USB 3.0 Type-A x 2 ports. Compatible with Mini ITX / Micro ATX / ATX / E-ATX motherboards. Accommodates up to 400mm GPUs. Houses 2 x 3.5” HDDs or 1+1 2.5” SSDs (converted from 3.5” drive bays). Mesh-Integrated Front Panel An all-metal front panel uses a rugged, snap-fit mechanism for a more snug connection that won’t shift or loosen easily. Integrating the ultra-fine mesh filter into the panel allows for tool-less, single-step maintenance without compromising filtration — just pop it out and snap it back into place. Preinstalled Cooling The MX230 RGB comes with preinstalled 3 x 120mm ARGB fans to the front and 1 x 120mm ARGB fan to the rear. Advanced Bottom-Up Cooling Most cases stop at two, but the MX230 RGB’s PSU shroud can seat 3 x 120mm fans. A truly porous, high-ventilation cover creates a vertical thermal column that feeds fresh intake directly to your components. Optimized Component Spacing Space between the motherboard and PSU shroud fans provides ample room for cabling and header connectors, clearing a path for seamless, efficient assembly. Optimal PSU Cabin Placement The PSU cabin is offset to the right of the case in contrast to the center placement of conventional PC case design, allowing for extra airflow from the side ventilation panel. Intake-Maximised Pedestal Perforated diagonal base slopes provide more intake real estate, drawing air through the angled mesh as well as offering a statuesque look. Refined Aesthetics The top mesh filter is rimmed with solid borders: preventing fraying and achieving a closer, more unified contact improves tactility and provides a polished and sophisticated appearance. Synchronized Lighting The built-in LED controller syncs with the motherboard for seamless system-wide lighting synchronization. Cooling Capacity Up to a 360mm AIO can be installed up top. A form factor-defying maximum capacity of 10 fans makes sure your build never burns out. Modern Connectivity The MX230 RGB is equipped with USB 3.2 Gen 2×1 Type-C (10bps) x 1, USB 3.0 Type-A x 2 ports for total and seamless connectivity with the latest peripherals and devices. Future-Ready GPU and Motherboard Compatibility The MX230 RGB is fully compatible with 400mm GPUs and E-ATX motherboards all within a compact mid tower form factor. Memory Capacity The MX230 RGB can house 2 x 3.5” HDDs or 1+1 2.5” SSDs (converted from 3.5” drive bays). Product Name: MX230 RGB Case Form Factor: Mid Tower Motherboard Type: Mini ITX / Micro ATX / ATX / E-ATX Dimensions (WxHxD): 220 x 475 x 445 (mm) I/O Panel: USB 3.2 Gen 2×1 Type-C x 1, USB 3.0 Type-A x 2, 4 Pole Headset Audio Jack x 1, RGB Button 3.5″ Drive Bay: 2 2.5″ Drive Bay: 1+1(converted from 3.5″ drive bays) Expansion Slots: 7 Cooling Fan Support Front: 120mm x 3 / 140mm x 2 Top: 120mm x 3 / 140mm x 2 PSU shroud: 120mm x 3 Rear: 120mm x 1 Pre-installed Fans Front: 120mm ARGB fan x 3 Rear: 120mm ARGB fan x 1 Speed: 1000 ± 10% RPM Connector: 5V 3 Pin (ARGB) / 3 Pin (Fan) Maximun Number of Fans: 10 Water Cooling Support Top: 360mm / 240mm / 120mm Rear: 120mm RGB Hub Sync with M/B: Yes Max. Graphics Card Length: 400 (mm) / 15.7 (in) Max. CPU Cooler Height: 170(mm) /6.7 (in) Max. PSU Length: 200 (mm) / 7.9 (in)
