DEEPCOOL CC550 4F ARGB ATX Mid Tower Case with 4 Pre-Installed Fans
MPN R-CC550BKANA4-G · Brand DEEPCOOL · ATX, mATX, Mini-ITX
The DEEPCOOL CC550 4F ATX Mid Tower Case ships with four 120mm ARGB fans, extensive mesh airflow panels, and supports ATX/M-ATX/M-ITX motherboards, GPUs up to 317mm, and up to eight fans total
Inclusive of GST · GST invoice available
Overview
The DEEPCOOL CC550 4F is an ATX mid-tower PC case designed for builders who want strong airflow, ARGB lighting, and broad hardware compatibility without compromise. Multiple large mesh panels line the chassis, enabling continuous, unobstructed airflow from intake to exhaust to help keep temperatures in check during extended sessions. Four 120mm ARGB fans come pre-installed, so your system is ready to cool and illuminate from the first boot. Should your thermal demands grow, the case supports up to eight fans in total. Fan mounting positions are distributed across the front (3×120mm), top (2×120mm or 2×140mm), bottom (2×120mm), and rear (1×120mm). Two dedicated 120mm fan mounts on the PSU shroud direct fresh air straight toward the GPU — a practical touch for high-load discrete graphics cards. If liquid cooling is on your roadmap, a 240mm radiator can be mounted at the top, with 120mm and 140mm options also supported. Hardware compatibility is generous across the board. The CC550 4F accepts ATX, Micro-ATX, and Mini-ITX motherboards, and can house CPU air coolers up to 163mm tall, graphics cards up to 317mm long, and power supply units up to 180mm in length. Seven expansion slots provide flexibility for multi-GPU or high-card-count configurations. Storage options include one 3.5-inch HDD bay and two 2.5-inch SSD bays (1+1 configuration). Cable routing benefits from 22mm of clearance behind the motherboard tray, and panels are tool-free removable for straightforward access during builds or upgrades. The front I/O panel keeps connectivity within easy reach: one USB 3.0 port, one USB 2.0 port, one USB Type-C port, and a combined audio/microphone jack. The chassis is constructed from a combination of ABS plastic, SPCC steel, and tempered glass, finished in black. A 1-year manufacturer warranty is included. Verified Specifications: - Form Factor: ATX Mid Tower - Motherboard Support: ATX, Micro-ATX, Mini-ITX - Pre-Installed Fans: 4 × 120mm ARGB - Total Fan Support: Up to 8 - Fan Positions: Front 3×120mm | Top 2×120mm/2×140mm | Bottom 2×120mm | Rear 1×120mm - Radiator Support: Top 240mm / 140mm / 120mm - Max CPU Cooler Height: 163mm - Max GPU Length: 317mm - Max PSU Length: 180mm - Storage: 1 × 3.5" HDD, 2 × 2.5" SSD - Expansion Slots: 7 - I/O: USB 3.0, USB 2.0, USB Type-C, Audio/Mic - Materials: ABS, SPCC, Tempered Glass - Colour: Black - Warranty: 1 Year
Datasheet
| Warranty | 1 Year |
|---|---|
| Form Factor | ATX, mATX, Mini-ITX |
| color | Black |
| Note*** | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only |
| Material | ABS,SPCC,Tempered Glass |
| I/O Panel | USB3.0,USB2.0,Type-C,Audio |
| Cabinet Size | MID-TOWER |
| Max 2.5" SSD | 1+1 |
| Max 3.5" HDD | 1 |
| Max GPU Length | 317mm |
| Max Psu Length | 180mm |
| Expansion Slots | 7 |
| Max Fan Support | 8 |
| Radiator Support | 240mm,140mm,120mm |
| Pre Installed Fans | 4 |
| Max CPU Cooler Height | 163mm |
