DeepCool CG530 4F ARGB ATX Mid Tower Case

The DeepCool CG530 4F is an ATX mid tower PC case engineered around a pillarless, non-A-pillar chassis design that pairs a full-height tempered glass side panel with a glass front panel. The result is an unobstructed, 270-degree view of your components, making every part of the build visible from multiple angles without any structural pillars breaking the sightline. Inside, the CG530 4F uses a dual-chamber layout that isolates the power supply and hard drives in a dedicated lower compartment, keeping the primary motherboard area free from cable clutter. This separation also creates distinct airflow channels so that PSU heat does not mix with the cooling path for the CPU and GPU. The case ships with four pre-installed PWM ARGB fans: three 120 mm reverse-blade fans mounted on the side intake panel and one standard 120 mm PWM ARGB fan at the rear exhaust. All four fans are PWM-controlled and addressable, allowing speed and lighting to be managed through a compatible motherboard header. The CG530 4F accommodates ATX, Micro-ATX, Mini-ITX, and rear-connector ATX or Micro-ATX motherboards. With a GPU clearance of 410 mm, a CPU cooler height limit of 160 mm, and a PSU maximum length of 210 mm (ATX PS2), there is room for high-end graphics cards and air coolers without modification. Seven expansion slots provide flexibility for multi-GPU configurations, capture cards, or other add-in cards. Cooling expandability is extensive. The side panel positions support up to three 120 mm or two 140 mm fans, or radiators up to 280 mm. The top can house a 120 mm, 140 mm, 240 mm, 280 mm, or 360 mm radiator, and the bottom supports 120 mm, 240 mm, or 360 mm configurations. The front panel does not support fan or radiator mounting per the manufacturer specification. Storage is handled by two 3.5-inch drive bays and three 2.5-inch drive bays (two dedicated plus one flex position). Front I/O includes two USB 3.0 Type-A ports, one USB 3.2 Gen 2 Type-C port, and a combined 3.5 mm audio/microphone jack. Magnetic dust filters are fitted at the top and bottom panels for straightforward maintenance. The rear of the chassis provides 45 mm of cable routing depth behind the motherboard tray, and maximum total fan support across all positions is ten fans. Verifiable Specifications: - Model: CG530 4F | P/N: R-CG530-BKADA4-G-1 - Dimensions: 440 × 285 × 399 mm (L × W × H) - Net Weight: 7.0 kg - Materials: ABS, SPCC steel, tempered glass - Motherboard Support: Mini-ITX, Micro-ATX, ATX (including rear-connector variants) - Pre-Installed Fans: 3 × 120 mm PWM ARGB reverse-blade (side) + 1 × 120 mm PWM ARGB (rear) - GPU Length Limit: 410 mm - CPU Cooler Height Limit: 160 mm - PSU Max Length: 210 mm (ATX PS2) - Expansion Slots: 7 - Drive Bays: 2 × 3.5-inch, 3 × 2.5-inch (2+1) - Front I/O: 2 × USB 3.0, 1 × USB 3.2 Gen 2 Type-C, 1 × Audio/Mic combo - Radiator Support: Top up to 360 mm, Side up to 280 mm, Bottom up to 360 mm - Dust Filters: Magnetic, top and bottom - Warranty: 1 Year
