EVGA SuperNova 1000 P5 Platinum 1000 Watt Fully Modular Smps

The EVGA SuperNova 1000 P5 Platinum (SKU: 220-P5-1000-X1) is a 1000-watt fully modular ATX power supply designed for high-performance desktop builds, including multi-GPU gaming rigs and workstation configurations. Holding an 80 PLUS Platinum certification, the unit delivers efficiency of 92% or higher at 115 VAC and 94% or higher at 220–240 VAC under typical loads, meaning less power is wasted as heat and your components receive cleaner, more stable electricity. The fully modular cable design allows you to connect only the cables your system actually needs, reducing internal clutter, improving airflow through the chassis, and making builds and upgrades significantly tidier. Eight PCIe 6+2 pin connectors provide ample headroom for dual high-end graphics cards, while 12 SATA connectors and 4 peripheral 4-pin connectors serve storage-dense builds. Inside, 100% Japanese capacitors are used throughout the power supply, chosen for their long-term reliability and consistent performance across thousands of hours of operation. The Active Clamp and DC-to-DC converter topology keeps voltage regulation tight on the 3.3 V and 5 V rails, and Active Power Factor Correction (PFC) reduces harmonic distortion on the mains supply. The 135 mm Fluid Dynamic Bearing (FDB) fan runs with lower friction and greater longevity than sleeve-bearing alternatives. The EVGA ECO Intelligent Thermal Control System takes this further by allowing the fan to stop entirely at low-to-medium loads, making the power supply completely silent under everyday desktop usage. Comprehensive hardware protection is built in, covering Over Voltage Protection (OVP), Under Voltage Protection (UVP), Over Current Protection (OCP), Over Power Protection (OPP), Short Circuit Protection (SCP), and Over Temperature Protection (OTP). Verified Specifications: - Wattage: 1000 W - Efficiency Certification: 80 PLUS Platinum (92% @ 115 VAC / 94% @ 220–240 VAC, typical load) - Modular: Fully modular - Capacitors: 100% Japanese - Fan: 135 mm Fluid Dynamic Bearing - PCIe Connectors: 8 × (6+2)-pin - SATA Connectors: 12 - Peripheral (4-pin) Connectors: 4 - Dimensions: 86 mm (H) × 150 mm (W) × 200 mm (L) - Operating Temperature: 0°C to 50°C - MTBF: 100,000 hours - Warranty: 10 years - Certifications: TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS; ErP Lot 3 2014 compliant - GPU Compatibility: NVIDIA SLI and AMD CrossFire ready
