EVM 1TB Sata SSD

The EVM 1TB 2.5-Inch SATA SSD (SKU: EVM25-1TB) delivers solid-state performance in the standard 2.5-inch form factor, making it a straightforward upgrade for both laptops and desktop systems that feature a SATA bay. With sequential read speeds of up to 550 MB/s and sequential write speeds of up to 500 MB/s, everyday tasks such as operating-system boot, application loading, and large-file transfers complete noticeably faster compared to traditional mechanical hard drives. Storage media is 3D TLC NAND flash, and the drive uses an internal SRAM buffer in place of a dedicated DRAM cache. The controller is sourced from SMI, MAXIO, or YEESTOR depending on production batch — a common practice in this product tier and worth noting for workloads that benchmark intensively. The drive is compliant with Serial ATA Revision 2.6 and operates at both SATA 3.0 Gb/s and SATA 6.0 Gb/s interface rates, ensuring backward compatibility with older platforms while taking full advantage of SATA III bandwidth on modern systems. Data integrity is supported by a hardware LDPC ECC engine, bad-block management, and global dynamic and static wear leveling — all of which contribute to the drive's rated 340TB TBW (Total Bytes Written) endurance figure. Additional reliability features include TRIM support, DIPM/HIPM power-management modes, Native Command Queuing (NCQ), S.M.A.R.T. monitoring, and sudden power-off recovery to protect in-flight data during unexpected shutdowns. The drive is also rated to withstand electrostatic discharge up to ±4 kV and carries RoHS, CE, and FCC compliance. Operating temperature range is 0°C to 70°C, and the drive can be stored safely between -40°C and 85°C. EVM backs this SSD with a 5-year warranty. Verified Specifications: • Capacity: 1TB • Form Factor: 2.5-inch • Interface: SATA (SATA 6.0 Gb/s / SATA 3.0 Gb/s compatible) • NAND Type: 3D TLC NAND • Sequential Read: Up to 550 MB/s • Sequential Write: Up to 500 MB/s • TBW (Endurance): 340TB • ECC: Hardware LDPC • Operating Temperature: 0°C to 70°C • Storage Temperature: -40°C to 85°C • Compliance: RoHS, CE, FCC • Warranty: 5 Years • Compatible Systems: Desktop, Laptop, POS machines, and other SATA-equipped devices
