FRACTAL DESIGN Define 7 Compact ATX Mid Tower Cabinet (White)
MPN FD-DEFINE-7-COMPACT-WH · Brand Fractal Design · ATX, mATX, Mini-ITX
Features of FRACTAL DESIGN Define 7 Compact Solid Mid Tower Cabinet (White) (FD-C-DEF7C-05 ) The versatile layout of the Fractal Design allows you to maximize the potential of the small footprint with full-size ATX hardware to meet your exact needs. For example, you can easily fit GPUs up to 360 mm with a 240 mm radiator in the top – or up to 360/280 mm front radiators with GPUs under 305 mm.The new Define 7 Compact takes the strongest features of the contemporary 7 Series design and places them
Inclusive of GST · GST invoice available
Overview
Features of FRACTAL DESIGN Define 7 Compact Solid Mid Tower Cabinet (White) (FD-C-DEF7C-05 )
The versatile layout of the Fractal Design allows you to maximize the potential of the small footprint with full-size ATX hardware to meet your exact needs. For example, you can easily fit GPUs up to 360 mm with a 240 mm radiator in the top – or up to 360/280 mm front radiators with GPUs under 305 mm.The new Define 7 Compact takes the strongest features of the contemporary 7 Series design and places them in a conveniently compact frame.
Remarkably quiet
Solid construction with industrial high-density sound damping helps maintain whisper-quiet operation
Brushed aluminum front and top-latching side panels offer a clean sophisticated look
Top panel effortlessly swaps from solid steel to filtered ventilation
Substantial cooling
Install up to 7 x 120 mm or 4 x 140 mm fans, and radiators up to 360 mm
1 x 120 mm and 1 x 140 mm Dynamic X2 fans included
Ventilated PSU shroud with two-part removable cover for optimal coverage and front radiator support
Specifications of FRACTAL DESIGN Define 7 Compact ATX Mid Tower Cabinet
| Dimension: | 427 x 210 x 474 mm |
| Max GPU Length: | 341 mm (360 mm without front fan) |
| Max PSU Length: | 200 mm (with HDD cage and front fan) |
| Max CPU Cooler Height: | 169 mm |
| Expansion Slot: | 7 |
| DVD Drive Bay: | NA |
| 3.5: | 2 |
| 2.5: | 2 |
| USB 2.0 Port: | 2 x USB 2.0 |
| USB 3.0 Port: | 2 x USB 3.0 |
| Case Window: | Tempered Glass |
| Form Factor: | ATX / mATX / mITX |
| Radiator Compatibility: | Front radiator Up to 360/280 mm (max 145 mm width),Top radiator Up to 240 mm,Rear radiator 120 mm,Bottom radiator 120 mm (requires removal of HDD cage) |
| Warranty: | 2 Years |
Datasheet
| Warranty | 2 Years |
|---|---|
| Form Factor | ATX, mATX, Mini-ITX |
| 2.5 | 2 |
| 3.5 | 2 |
| Dimension | 427 x 210 x 474 mm |
| Case Window | Tempered Glass |
| USB 2.0 Port | 2 x USB 2.0 |
| USB 3.0 Port | 2 x USB 3.0 |
| Expansion Slot | 7 |
| Max GPU Length | 341 mm (360 mm without front fan) |
| Max Psu Length | 200 mm (with HDD cage and front fan) |
| Max CPU Cooler Height | 169 mm |
| Radiator Compatibility | Front radiator Up to 360/280 mm (max 145 mm width) ,Top radiator Up to 240 mm ,Rear radiator 120 mm,Bottom radiator 120 mm (requires removal of HDD cage) |
