FRACTAL DESIGN Focus 2 Mesh RGB Clear Tint ATX Mid Tower Cabinet (White)
MPN FD-C-FOC2A-04 · Brand Fractal Design · ATX, mATX, Mini-ITX
The Fractal Design Focus 2 Mesh RGB White ATX Mid Tower Cabinet pairs a steel-mesh front panel and clear-tint tempered glass side panel with two pre-installed Aspect 14 RGB fans, 360 mm front radiator support, and ATX/mATX/Mini-ITX motherboard compatibility
Inclusive of GST · GST invoice available
Overview
The Fractal Design Focus 2 Mesh RGB Clear Tint ATX Mid Tower Cabinet in White is a thoughtfully engineered PC enclosure designed to balance strong airflow, clean aesthetics, and flexible component compatibility. Its steel-mesh front panel acts as a combined intake grille and dust filter, drawing cool air directly over your components while keeping debris out. A clear-tint tempered glass side panel secured with captive thumbscrews lets you display your build without tools, and a stylish cable-cover panel tucked behind the glass keeps wiring tidy and out of sight. This RGB variant ships with two pre-installed Fractal Design Aspect 14 RGB 140 mm fans at the front, backed by an integrated addressable RGB controller accessible from the front I/O. The interior layout has been designed to channel airflow front-to-back efficiently, with room to add up to six 120 mm fans or four 140 mm fans across front, top, and rear positions. Radiator builders are well-served: the case accepts up to a 360 mm radiator in the front, a 240 mm radiator on the top (with a maximum RAM clearance of 46 mm), and a 120 mm radiator at the rear. Compatibility is broad: the Focus 2 supports ATX, Micro-ATX, and Mini-ITX motherboards, accepts ATX power supplies up to 250 mm long (175 mm recommended for best cable clearance), and accommodates GPUs up to 405 mm in length with the front fans installed. CPU coolers up to 170 mm tall are supported. Storage options include two dedicated 2.5-inch mounts included out of the box with six total 2.5-inch positions available, plus two dedicated 3.5-inch drive bays. Seven expansion slots provide ample room for multi-card or high-end GPU setups. The front I/O panel features two USB 3.0 (5 Gb/s) ports and combined mic/headphone audio jacks, with RGB power LEDs in this version. An optional USB-C upgrade kit is available separately for users who need a front-facing Type-C port. Cable management is supported by 19 mm of routing space behind the motherboard tray, and three dust filters—steel mesh at the front, plastic mesh on top, and nylon at the PSU intake—help maintain system cleanliness. Verified Specifications: - Form factor: ATX Mid Tower - Motherboard support: ATX / Micro-ATX / Mini-ITX - Dimensions (L×W×H): 472 × 215 × 451 mm (with feet); 459 × 215 × 437 mm (without protrusions) - Net weight: 6.4 kg (TG version) - Pre-installed fans: 2× Fractal Design Aspect 14 RGB (140 mm, front) - Total fan mounts: 6× 120 mm or 4× 140 mm - Front radiator: up to 360 mm - Top radiator: up to 240 mm (max 46 mm RAM height) - Rear radiator: up to 120 mm - GPU max length: 405 mm (with front fan mounted) - CPU cooler max height: 170 mm - PSU max length: 250 mm (175 mm recommended) - Drive mounts: 2× 3.5-inch, 2 included / 6 total 2.5-inch - Expansion slots: 7 - Front I/O: 2× USB 3.0, audio jacks, addressable RGB controller - Cable routing space: 19 mm - Dust filters: front (steel mesh), top (plastic mesh), PSU (nylon) - Left panel: tempered glass (TG version); Right panel: steel - Warranty: 2 years
Datasheet
| Warranty | 2 Years |
|---|---|
| Form Factor | ATX, mATX, Mini-ITX |
| Color | White |
| Top Fan | 2x 120/140 mm |
| Rear Fan | Place for 1x 120 mm (not included) |
| Net Weight | TG: 6,4 kg, Solid: 6,1 kg |
| Dust Filters | Top (plastic mesh, PSU (nylon), Front (steel mesh) |
| Gross Weight | TG: 7,9 kg, Solid: 7,6 kg |
| Top Radiator | Up to 240 mm (max 46 mm RAM height) |
| Rear Radiator | Up to 120 mm |
| Front Radiator | Up to 360 mm |
| GPU Max Length | 405 mm with front fan mounted |
| Psu Max Length | 250 mm (175 mm recommended) |
| Expansion Slots | 7 |
| Front Interface | 2x USB 3.0, Audio (RGB controller included in RGB version) |
| Left Side Panel | Steel or tempered glass (RGB version: tempered glass only) |
| Fixed Cable Ties | No |
| Right Side Panel | Steel |
| Total Fan Mounts | 6x 120 mm or 4x 140 mm |
| Power Supply Type | ATX |
| Cable Routing Space | 19 mm |
| Captive Thumbscrews | Side Panels |
| CPU Cooler Max Height | 170 mm |
| Case Dimensions (Lxwxh) | 472 x 215 x 451 mm |
| Front Fan (Rgb Version) | 2x Aspect 14 RGB included |
| Motherboard Compatibility | ATX / mATX / Mini ITX |
| Package Dimensions (Lxwxh) | 539 x 305 x 538 mm |
| Dedicated 2.5" Drive Mounts | 2 included, 6 total |
| Dedicated 3.5" Drive Mounts | 2 (included) |
| Front Fan (Non-Rgb Version) | 2x Aspect 14 included |
| Case Dimensions W/O Feet/Protrusions/Screws (Lxwxh) | 459 x 215 x 437 mm |
| Note*** | Features, Price and Specifications are subject to change without notice. Images used for representation purposes Only |
| Material | Steel,Tempered Glass |
| Cabinet Size | MID-TOWER |
| Max 2.5" SSD | 2 |
| Max 3.5" HDD | 2 |
| Max GPU Length | 405mm |
| Max Psu Length | 250mm |
| Front I/O Panel | USB 3.0, Audio (RGB controller included in RGB version) |
| Max Fan Support | 5 |
| Radiator Support | 360mm,280mm,240mm,140mm,120mm |
| Pre Installed Fans | 2 |
| Max CPU Cooler Height | 170mm |
