Fractal Design Meshify 3 XL Ambience pro RGB TG Light Tint SSI-EEB Full Tower Case

The Fractal Design Meshify 3 XL Ambience Pro RGB TG Light Tint is a full-tower PC case engineered for builders who demand maximum airflow, expansive hardware compatibility, and advanced ambient lighting in a single chassis. Built around a rockface-inspired mesh front panel, the case channels air efficiently across the interior while delivering a striking aerodynamic aesthetic. At the heart of this build-ready enclosure is support for the largest mainstream and workstation motherboard standards, including SSI-EEB, SSI-CEB, E-ATX (up to 330 mm width), ATX, mATX, and Mini-ITX. A generous 512 mm GPU clearance accommodates the longest current-generation graphics cards, while a 182 mm CPU cooler height limit supports tall air coolers and 360 mm or larger AIO radiators. Cooling potential is exceptional. The case ships with three Momentum 14 fans featuring LCP blades and true fluid dynamic bearings (FDB), pre-installed in the front intake position. Total fan mounting capacity reaches 10 x 140 mm positions or 7 x 120 mm positions across front, top, and rear locations. Radiator support extends to 420 mm (up to 475 mm) at the top, 360 mm at the front and side, and up to 140 mm at the rear, making this chassis well suited to custom liquid cooling loops. The Ambience Pro RGB version includes the Adjust Pro Hub for controlling ARGB Gen 2 ambient lighting and fan speeds through a download-free configuration tool. The lighting system supports an animated PC startup effect for a distinctive visual impression on every boot. Storage flexibility covers two 3.5-inch HDD mounts and five 2.5-inch SSD mount positions (four combined plus one dedicated). Cable management is simplified by 37.5 mm of routing space behind the motherboard tray, a full cable cover, three hook-and-loop straps, and three cable aligners. Seven expansion slots accommodate multi-GPU or high-profile PCIe add-in cards. The top I/O panel includes one USB Type-C port at 20 Gbps, two USB Type-A ports at 5 Gbps, and a combined audio jack. The ATX power supply bay accepts units up to 230 mm in length. Verified Specifications: - Form factor: Full Tower - Motherboard support: SSI-EEB / SSI-CEB / E-ATX (330 mm) / ATX / mATX / Mini-ITX - GPU max length: 512 mm - CPU cooler max height: 182 mm - PSU max length: 230 mm - Pre-installed fans: 3 x Momentum 14 (140 mm, FDB bearings) - Total fan mounts: 10 x 140 mm / 7 x 120 mm - Top radiator: up to 420 mm (475 mm with bracket) - Front radiator: 280 / 360 mm - Side radiator: 360 mm - Rear radiator: up to 140 mm - 3.5-inch drive mounts: 2 - 2.5-inch drive mounts: 4 combined + 1 dedicated - Expansion slots: 7 - Front I/O: 1 x USB-C 20 Gbps, 2 x USB-A 5 Gbps, 1 x Audio Combo Jack - Lighting: ARGB Gen 2 Ambience Pro RGB with Adjust Pro Hub - Dust filter: PSU bottom - Side panel: Tempered glass (light tint) left / Steel right - Warranty: 2 Years - SKU: FD-C-MES3X-03
