Fractal Design North Chalk TG Clear (ATX) Mid Tower Cabinet (White)
MPN FD-C-NOR1C-04 · Brand FRACTAL DESIGN · ATX, mATX, Mini-ITX
The Fractal Design North Chalk TG Clear (White) is an ATX mid-tower case featuring a Red Dot 2023 Award-winning natural-wood front design, two pre-installed 140 mm PWM fans, 360 mm front radiator support, and a 355 mm GPU clearance with tempered glass side panel
Inclusive of GST · GST invoice available
Overview
The Fractal Design North Chalk TG Clear (FD-C-NOR1C-04) is an ATX mid-tower cabinet finished in White that brings a distinctive natural aesthetic to the desktop or living room setup. Fractal Design built the North around real wood front panels — available in walnut or oak — paired with faux leather and steel or brass accents, earning the case a Red Dot Design Award in 2023. The tempered glass clear side panel lets you showcase the interior while the fine-patterned mesh front and top panels keep airflow unrestricted. The North ships with two 140 mm Aspect PWM fans pre-installed at the front, giving your build an immediate thermal baseline. The case accommodates up to three 120 mm or two 140 mm fans at the front, two 120/140 mm fans at the top, and one 120 mm fan at the rear, for a maximum of eight 120 mm or six 140 mm fan positions. Cooling flexibility extends to liquid loops as well: the front accepts radiators up to 360 mm, the top supports up to 240 mm, and the rear can house a 120 mm unit. GPU builders will appreciate a maximum graphics card length of 355 mm whether front fans are installed or not, while CPU cooler clearance reaches 170 mm without a front radiator fitted (145 mm when the mesh-version fan bracket is used). The motherboard tray accepts ATX, mATX, and Mini-ITX boards, with an ATX power supply mounted at the base. Cable management is aided by 30 mm of routing space behind the motherboard tray, cable routing grommets, and fixed cable straps. Storage options include two dedicated 2.5-inch SSD mounts and two combined 3.5/2.5-inch trays, with the product page indicating a total of up to four 2.5-inch SSD positions. The front I/O panel provides one USB 3.1 Gen 2 Type-C port with fast-charging support and speeds up to 10 Gbps, two USB 3.0 ports, plus combined audio and microphone jacks. Seven bridgeless expansion slots support multi-GPU and high-profile card configurations. Verified Specifications: - Model: FD-C-NOR1C-04 - Form factor: ATX / mATX / Mini-ITX - Dimensions (L×W×H): 447 × 215 × 469 mm; without feet/protrusions: 433.5 × 215 × 450 mm - Net weight: 7.7 kg | Gross weight: 9.3 kg - Pre-installed fans: 2 × Aspect 140 mm PWM (front) - Total fan mounts: 8 × 120 mm or 6 × 140 mm - Front radiator: up to 360 mm | Top radiator: up to 240 mm | Rear radiator: 120 mm - GPU max length: 355 mm - CPU cooler max height: 170 mm (without front radiator) - PSU type: ATX | PSU bay 1 max: 255 mm | PSU bay 2 max: 155 mm - Storage: 2 dedicated 2.5-inch mounts + 2 combined 3.5/2.5-inch mounts - Expansion slots: 7 bridgeless - Front I/O: 1 × USB 3.1 Gen 2 Type-C, 2 × USB 3.0, Audio & Mic - Cable routing space: 30 mm - Dust filters: Front, PSU - Warranty: 2 Years
Datasheet
| Warranty | 2 Years |
|---|---|
| Form Factor | ATX, mATX, Mini-ITX |
| color | White |
| Note*** | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only |
| Top Fan | 2 x 120/140 mm |
| Material | Steel |
| Rear Fan | 1 x 120 mm |
| Front Fan | 3 x 120, 2 x 140 mm (2 x Aspect 140 mm PWM Included) |
| Net Weight | 7.7kg |
| Cabinet Size | MID-TOWER |
| Dust Filters | Front, Bottom |
| Gross Weight | 9.3kg |
| Max 2.5" SSD | 4 |
| Max 3.5" HDD | 2 |
| Model | FD-C-NOR1C-04 |
| Top Radiator | Up to 240 mm (See manual for details on ram clearance) |
| Rear Radiator | 1 x 120 mm (If using a rear radiator the mesh version fan bracket can only be slotted into the bottom position) |
| Front Radiator | Up to 360 mm |
| GPU Max Length | 355 mm with and without front fan mounted |
| Max GPU Length | 355mm |
| Max Psu Length | 155mm |
| Psu Max Length | 1 HDD Tray: 255 mm max, 2 HDD Tray: 155 mm max |
| Expansion Slots | 7 |
| Front I/O Panel | USB 3.1 Gen 2 Type-C, USB 3.0, Audio & Mic |
| Front Interface | 1xUSB 3.1 Gen 2 Type-C, 2xUSB 3.0, Audio & Mic |
| Max Fan Support | 8 |
| Radiator Support | 360mm,280mm,240mm,140mm,120mm |
| Total Fan Mounts | 8 x 120 mm or 6 x 140 mm |
| Power Supply Type | ATX |
| Fixed Cable Straps | Yes |
| Pre Installed Fans | 2 |
| Cable Routing Space | 30 mm |
| Captive Thumbscrews | HDD brackets, SSD bracket, Side Panels, Fan Bracket, PSU Bracket |
| 5.25” Drive Mounts | 0 |
| CPU Cooler Max Height | 145 mm with Fan Bracket (Mesh version only)/ 170 mm w.o |
| Max CPU Cooler Height | 145mm |
| Cable Routing Grommets | Yes |
| Case Dimensions (Lxwxh) | 447 x 215 x 469 mm |
| Motherboard Compatibility | ATX / mATX / Mini-ITX |
| Package Dimensions (Lxwxh) | 565 x 326 x 553 mm |
| Dedicated 2.5" Drive Mounts | 2 |
| Combined 3.5/2.5” Drive Mounts | 2 (included) |
| Case Dimensions W/O Feet/Protrusions/Screws | 433,5 x 215 x 450 mm |
