Fractal Design North XL TG Clear (E-ATX) Mid Tower Cabinet (White)

The Fractal Design North XL TG Clear is a spacious E-ATX mid tower cabinet finished in white, combining natural material accents with well-engineered airflow in a form factor suited to both dedicated gaming setups and living-room builds. The front panel features FSC-certified wood bars — available in oak or walnut — alongside faux leather details and steel or brass trim, giving the chassis a distinct aesthetic among steel-bodied cases. Airflow is served by an open-front ventilation path and a mesh-integrated top panel. The TG Clear variant ships with a clear tempered glass side panel for component visibility, while the top and front mesh work together to move air efficiently without requiring aggressive fan speeds. Three Fractal Design Aspect 140mm PWM fans are pre-installed at the front, providing immediate out-of-box airflow. The interior accommodates E-ATX, ATX, mATX, and Mini-ITX motherboards within a 503 × 240 × 509 mm chassis. GPU clearance reaches 413 mm with front fans mounted, or 380 mm when a 33 mm-thick 420/360 mm front radiator is installed. CPU coolers up to 155 mm tall are supported. Radiator mounts span front (up to 420/360 mm), top (up to 360/280 mm), and rear (120/140 mm). The case supports up to 7 × 120 mm or 6 × 140 mm fans in total across all mounts. Storage options include two dedicated 2.5-inch SSD mounts and two combined 3.5/2.5-inch drive bays. Cable management is aided by 29 mm of routing space behind the motherboard tray, rubber-grommetted cable pass-throughs, and fixed cable straps. Captive thumbscrews are used on HDD brackets, the SSD bracket, side panels, fan bracket, and PSU bracket for tool-free accessibility. The front I/O panel provides one USB 3.1 Gen 2 Type-C port (up to 20 Gbps), two USB 3.0 ports, and a combined audio and microphone jack. The ATX power supply bay accommodates units up to 290 mm with one HDD tray installed, or 175 mm with both trays in place. Dust filtration is present at the front and PSU intake. Seven expansion slots are available. Verified Specifications: - Model: FD-C-NOR1X-04 - Form Factor: Mid Tower - Motherboard Support: E-ATX / ATX / mATX / Mini-ITX - Case Dimensions (L×W×H): 503 × 240 × 509 mm - Net Weight: 9.5 kg - GPU Max Length: 413 mm (front fan mounted) / 380 mm (33 mm-thick 420/360 mm radiator) - Max CPU Cooler Height: 155 mm - Front Radiator: Up to 420/360 mm - Top Radiator: Up to 360/280 mm - Rear Radiator: 120/140 mm - Total Fan Mounts: 7 × 120 mm or 6 × 140 mm - Pre-installed Fans: 3 × Aspect 140mm PWM - Front I/O: 1× USB 3.1 Gen 2 Type-C, 2× USB 3.0, Audio & Mic - Storage: 2× dedicated 2.5" + 2× combined 3.5"/2.5" - Expansion Slots: 7 - Cable Routing Space: 29 mm - Material: Steel - Color: White - Warranty: 2 Years
