Features of FRACTAL DESIGN Terra MITX ATX Mini Tower Cabinet (Graphite)
• Install your choice of powerful GPU up to 322 mm in length, in a space-saving 10.4 L case (excluding feet)
• Add natural materials to your setup with a front-facing panel cut from FSC-certified solid walnut
• Enjoy a sleek anodized aluminum exterior including an 8 mm-thick aluminum front
Terra is a Fractal Design cabinet designed and engineered to reshape the small form factor gaming experience. Inspired by the homes of modern gamers, Terra incorporates boutique design features such as thick panels cut from anodized aluminum, CNC-milled details and FSC-certified solid walnut. Inside, it includes a PCIe 4.0 riser cable and features a stepless slidable central wall for build flexibility, providing space for a powerful GPU up to 322 mm in length.
Elegantly crafted
- Add natural materials to your setup with a front-facing panel cut from FSC-certified solid walnut
- Enjoy a sleek anodized aluminum exterior including an 8 mm-thick aluminum front
- Make the most of natural airflow through the ventilated top, side and bottom panels
Elegantly crafted
- Add natural materials to your setup with a front-facing panel cut from FSC-certified solid walnut
- Enjoy a sleek anodized aluminum exterior including an 8 mm-thick aluminum front
- Make the most of natural airflow through the ventilated top, side and bottom panels
Engineered for SFF gaming
- Experience powerful, uncluttered gaming, with the ability to install a GPU up to 322 mm long in a space-saving 10.4 L case (excluding feet)
- Get a head start on your build with the included PCIe 4.0 riser cable
- Store up to two SSDs in the dedicated 2.5” drive mounts
Get the affordable cpu cabient price with the huge variety with us!
Specifications of FRACTAL DESIGN Terra MITX ATX Mini Tower Cabinet (Graphite)
| Model Name | FRACTAL DESIGN Terra /FD-C-TER1N-01 |
| Dedicated 2.5″ drive mounts | 42 (included) |
| Expansion slots | 3 (Max GPU Mode), 2 (Max CPU-Cooler height mode) |
| Front interface | 1x USB Type-C 20Gbps (USB 3.2 Gen 2×2), 1x USB Type-A 5Gbps (USB 3.0), Power Button |
| Total fan mounts | 1x 120 mm |
| Bottom fan | 1x 120 mm |
| Tool-less push-to-lock | Both side panels and top panel (can also be locked with screws) |
| Compatibility | |
| Motherboard compatibility | Mini ITX |
| Power supply type | SFX-L/ SFX |
| Side radiator | 1x 120mm (121 mm wide if max 200 mm GPU and no SSDs) |
| PSU max length | 130 mm |
| GPU max length | 322 mm |
| GPU max width (if GPU height is lower than 131 mm) | 72 mm (Configured for Max GPU) / 43 mm (Configured for Max CPU-Cooler) |
| GPU max width (if GPU height 131-145mm) | 62 mm (Configured for Max GPU) / 33 mm (Configured for Max CPU-Cooler) |
| CPU cooler max height | 145 mm (Configured for Max GPU) / 131 mm (Configured for Max CPU-Cooler) |
| Dimensions | |
| Case dimensions | 343 x 153 x 218 mm |
| Case dimensions w/o feet/protrusions/screws | 343 x 153 x 198 mm |
| Net weight | 3.1 kg |
| Package dimensions (LxWxH) | 394 x 215 x 292 mm |
| Gross weight | 4.0 kg |
| Volume | 10.4 liter (excluding feet), 11.4 liter (external dimensions) |
| Warranty | 2 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
