GALAX Revolution 05 Mesh RGB ATX Mid Tower Cabinet (White)
MPN GALAX-REVOLUTION-05-MESH-RGB-ATX-MID-TOWER-c5a4e0 · Brand GALAX · ATX, M-ATX, ITX
Features of GALAX Revolution 05 Mesh RGB ATX Mid Tower Cabinet (White) Now available in arctic white color, REV-05W is by far the tallest PC case in the Revolution family and is compatible with ATX, M-ATX, ITX motherboards. Standing tall at 470mm, it provides a spacious interior for customization, allowing you to choose between vertical or horizontal mounting for the graphics card and maximizing cooling and storage potential for your next build. Specifications of GALAX Revolution 05 Mesh RGB ATX
Inclusive of GST · GST invoice available
Overview
Features of GALAX Revolution 05 Mesh RGB ATX Mid Tower Cabinet (White)
Now available in arctic white color, REV-05W is by far the tallest PC case in the Revolution family and is compatible with ATX, M-ATX, ITX motherboards. Standing tall at 470mm, it provides a spacious interior for customization, allowing you to choose between vertical or horizontal mounting for the graphics card and maximizing cooling and storage potential for your next build.
Specifications of GALAX Revolution 05 Mesh RGB ATX Mid Tower Cabinet (White)
| Form Factor (Midi, Micro, Mini ITX, Full) | ATX, M-ATX, ITX |
| Chassis | SPCC + Tempered Glass |
| PSU Form Factor | ATX |
| M/B Form Factor | ATX, M-ATX, ITX |
| Front Panel | ABS,Mesh cover |
| Top Panel | Metal cover |
| Side Panel | |
| Left | Tempered Glass |
| Right | Metal cover |
| External Drive Bay(s) | |
| 5.25" (ODD) | *0 |
| 3.5" | *0 |
| Internal Drive Bay(s) | |
| 3.5" (HDD) | *2 |
| 2.5" (SSD) | *3 |
| I/O | |
| Buttons | *2 |
| USB1.1 Port(s) | *0 |
| USB2.0 Port(s) | *2 |
| USB3.0 Port(s) | *1 |
| USB3.1 Port(s) | *0 |
| HD Audio Support | *1 |
| Card Reader (Support) | *0 |
| P-Lock | *0 |
| RGB Controller | *0 |
| Controller max. fans | *0 |
| RGB Controller max. LED strips | *0 |
| Remote (IR or RF) | *0 |
| Cooling Fan Support | |
| Front | 3x120mm (Fan optional) |
| Top | 2x120mm，2x140mm (Fan optional) |
| Rear | 1x120mm (Fan optional) |
| Side | 0 |
| Bottom | 2x120mm (Fan optional) |
| Water Cooling Support (Radiator Size) | |
| Front | 240mm/280mm/360mm |
| Top | 240mm/280mm |
| Rear | 120mm |
| Dimensions | |
| Chassis | (L)350*(W)205*(H)470mm |
| Full Case (inc Fascia) | (L)400.6*(W)205*(H)481.5mm |
| Carton | (L)532*(W)258*(H)465mm |
| Net Weight (Kg) | 4.3KG |
| Product Code | CGG5ANWA4B0 |
| VGA Card Length | up to 330mm |
| CPU Cooler Height | 160mm |
| Cable Management Depth | 18mm |
| Warranty | 1 Year |
| Note | *** Features, Price, Specifications are subject to change without notice. |
Datasheet
| Warranty | 1 Year |
|---|---|
| Top | 240mm/280mm |
| 3.5" | *0 |
| Left | Tempered Glass |
| Rear | 120mm |
| Side | 0 |
| Front | 240mm/280mm/360mm |
| Right | Metal cover |
| Bottom | 2x120mm (Fan optional) |
| Carton | (L)532*(W)258*(H)465mm |
| P-Lock | *0 |
| Buttons | *2 |
| Chassis | (L)350*(W)205*(H)470mm |
| Top Panel | Metal cover |
| 2.5" (Ssd) | *3 |
| 3.5" (Hdd) | *2 |
| 5.25" (Odd) | *0 |
| Front Panel | ABS,Mesh cover |
| Product Code | CGG5ANWA4B0 |
| RGB Controller | *0 |
| Usb1.1 Port(S) | *0 |
| Usb2.0 Port(S) | *2 |
| Usb3.0 Port(S) | *1 |
| Usb3.1 Port(S) | *0 |
| M/B Form Factor | ATX, M-ATX, ITX |
| Net Weight (Kg) | 4.3KG |
| Psu Form Factor | ATX |
| Vga Card Length | up to 330mm |
| Hd Audio Support | *1 |
| CPU Cooler Height | 160mm |
| Remote (Ir Or Rf) | *0 |
| Controller Max. Fans | *0 |
| Card Reader (Support) | *0 |
| Cable Management Depth | 18mm |
| Full Case (Inc Fascia) | (L)400.6*(W)205*(H)481.5mm |
| RGB Controller Max. Led Strips | *0 |
| Form Factor (Midi, Micro, Mini Itx, Full) | ATX, M-ATX, ITX |
