Gamdias Helios P2-850G 850 Watt 80 Plus Gold ATX 3.0 SMPS

The Gamdias Helios P2-850G is an 850-watt power supply built for modern high-performance gaming and workstation builds. Carrying the ATX12V v3.0 standard, it is fully compatible with PCIe Gen 5.0 graphics cards and features a native 16-pin 12VHPWR connector capable of delivering up to 450W to the GPU — making it a strong match for current-generation NVIDIA and AMD flagship cards. Efficiency sits at the 80 Plus Gold tier, which translates to up to 92% efficiency at 50% load. A high-quality Active Power Factor Correction (APFC) stage keeps the power factor value at 0.99, contributing to cleaner power draw from the wall. The DC-to-DC converter topology, combined with a full-bridge LLC resonant circuit and 12V synchronous rectification, ensures a rock-solid +12V rail output — the rail most critical to CPU and GPU stability under gaming and sustained workloads. Thermal management is handled by a 120mm hydraulic bearing fan. A smart fan controller modulates speed based on system load, allowing the PSU to operate quietly during light workloads. The unit is also rated to support C6/C7 low-power states and carries ErP Lot 6 environmental compliance. The comprehensive protection suite covers six distinct scenarios: Over Current Protection (OCP), Over Voltage Protection (OVP), Under Voltage Protection (UVP), Over Power Protection (OPP), Over Temperature Protection (OTP), and Short Circuit Protection (SCP) — providing a reliable safety net for the entire system. Connector support is extensive, including one 24-pin main power, two 4+4-pin CPU EPS, four 6+2-pin PCIe, one 12+4-pin 12VHPWR, six SATA, and three 4-pin Molex. Flat cables are included for easier routing, though the unit is a non-modular design. Verified Specifications: - Model: HELIOS P2-850G - Form Factor: ATX12V v3.0 - Total Power: 850W | Peak Power: 1105W - Efficiency: 80 Plus Gold (up to 92% at 50% load) - +12V Rail: 70.8A maximum - +3.3V / +5V Rail: 20A / 20A (combined 100W max) - AC Input: 100–240V~ / 12–6A / 50–60Hz - Cooling: 120mm hydraulic bearing fan - Dimensions (L x W x H): 140 x 150 x 86 mm - Protections: OVP, UVP, OPP, SCP, OCP, OTP - Connectors: 1x 24-pin, 2x 4+4-pin EPS, 4x 6+2-pin PCIe, 1x 12+4-pin 12VHPWR, 6x SATA, 3x Molex - Modular: Non-Modular (flat cables included) - Warranty: 3 Years - Environmental: ErP Lot 6 - MB Sync: Not supported
