GIGABYTE Aorus Elite 1000W Platinum ICE Fully Modular Smps

The GIGABYTE Aorus Elite 1000W Platinum ICE (GP-AE1000PM-PG5) is a fully modular power supply designed for high-performance desktop systems, including those powered by the latest PCIe Gen 5 graphics cards. Fully compliant with the Intel ATX 3.1 standard, it supports power excursions of up to 200% of rated power, ensuring stable delivery even during intense GPU transient spikes — up to 3× GPU power and 2× total system power. Dual certification from both 80 PLUS and Cybenetics at the Platinum efficiency tier means the unit wastes less energy as heat, contributing to lower system temperatures and quieter operation overall. Cybenetics LAMBDA A++ certification further recognises its near-silent acoustic performance. A 120mm Fluid Dynamic Bearing (FDB) smart fan remains completely off under low loads (below 50% load), activating only when the thermal situation demands it, with noise staying below 20 dBA under most conditions. All internal capacitors are sourced from Japanese manufacturers, selected for their consistency and longevity in demanding thermal environments. The power supply routes all current through a single +12V rail rated at 83.3A (999.6W combined), simplifying cable routing and maximising compatibility with modern components. At just 140mm in length, this unit fits comfortably inside compact and mid-tower chassis without sacrificing capacity or modular flexibility. The embossed fully modular cable system lets builders connect only the cables required, improving internal airflow and cable management. A native 16-pin (12VHPWR) cable is included for direct PCIe Gen 5 GPU connectivity, delivering up to 600W over a single connector. A decorative AORUS magnetic plate can be repositioned on different sides of the unit to showcase the AORUS logo at the preferred angle within the chassis window. Verified Specifications: • Model: GP-AE1000PM-PG5 ICE • Rated Output: 1000W • Standard: ATX 3.1 / PCIe Gen 5.1 • Efficiency: 80 PLUS Platinum + Cybenetics Platinum • +3.3V Rail: 25A | +5V Rail: 25A (combined 125W) • +12V Rail: 83.3A (999.6W) • -12V Rail: 0.3A (3.6W) | +5Vsb: 3A (15W) • Input Voltage: 100–240V AC, 50–60Hz, Active PFC • Fan: 120mm FDB smart fan (semi-passive, <20 dBA) • Length: 140mm • Modular: Fully modular with embossed cables • PCIe Connectors (6+2 pin): 6 • SATA Connectors: 8 • Peripheral (4-pin): 4 • Protections: OCP, OVP, OPP, UVP, SCP, OTP, NLO, SIP • Warranty: 10 years (region-adjusted)
