Gigabyte B760M Gaming AC DDR4 M-ATX Gen5 Motherboard
MPN B760M-GAMING-AC-DDR4-GEN5 · Brand GIGABYTE · mATX
Gigabyte B760M Gaming AC DDR4 Micro-ATX motherboard with Intel LGA1700 socket, PCIe 5.0 x16 slot, dual DDR4 up to 64 GB, 2.5GbE LAN, Wi-Fi 802.11ac, and Q-Flash Plus BIOS update support
Inclusive of GST · GST invoice available
Overview
The Gigabyte B760M Gaming AC DDR4 is a Micro-ATX motherboard built on Intel's B760 chipset with an LGA1700 socket, making it compatible with Intel Core 12th, 13th, and 14th generation processors, as well as Pentium and Celeron LGA1700 CPUs. Designed for compact yet capable gaming builds, this board packs PCIe 5.0 x16 connectivity into the mATX form factor — allowing you to install the latest generation graphics cards or NVMe SSDs without sacrificing bandwidth. Memory performance is handled by two DDR4 DIMM slots supporting dual-channel configuration with up to 64 GB of system memory (32 GB per slot). The board supports XMP profiles and DDR4 speeds ranging from 2133 MT/s up to 5333 MT/s (overclocked), giving builders meaningful headroom for memory tuning. ECC un-buffered modules are also supported in non-ECC mode. Storage expandability is well covered with two PCIe 4.0 x4 M.2 connectors for high-speed NVMe drives, supplemented by four SATA 6 Gb/s ports. The rear I/O provides a USB Type-C port (USB 3.2 Gen 1), three USB 3.2 Gen 1 Type-A ports, two USB 2.0 ports, and legacy PS/2 connectivity — versatile enough for both modern and existing peripherals. Networking centres on a 2.5 GbE wired LAN port and an integrated Wi-Fi 802.11ac module. A dedicated WIFI EZ-Plug connector simplifies antenna installation, while Gigabyte's WIFI Compass feature assists in orienting the antenna for optimal signal reception. Bluetooth 5.0 is also included. Display outputs on the rear I/O cover DisplayPort, HDMI, and D-Sub (VGA), supporting three simultaneous display configurations when using integrated graphics. The Smart Fan 6 system manages multiple fan headers with FAN STOP capability for silent operation during light workloads, and three ARGB/RGB headers (two Gen2 addressable, one standard) support LED strip customisation. Q-Flash Plus enables BIOS updates without a CPU, memory, or GPU installed — a practical feature during platform bring-up. Key Specifications: • Socket: LGA1700 | Chipset: Intel B760 | Form Factor: Micro-ATX • CPU Support: Intel Core 12th / 13th / 14th Gen, Pentium, Celeron (LGA1700) • Memory: 2 x DDR4 DIMM, dual-channel, up to 64 GB (32 GB per DIMM), DDR4-2133 to DDR4-5333 (O.C.), XMP support • PCIe: 1 x PCIe 5.0 x16 (CPU) | 1 x PCIe 3.0 x1 (chipset) • Storage: 2 x M.2 PCIe 4.0 x4 | 4 x SATA 6 Gb/s • Networking: 2.5 GbE LAN | Wi-Fi 802.11ac | Bluetooth 5.0 • Rear USB: 1 x USB-C 3.2 Gen 1, 3 x USB-A 3.2 Gen 1, 2 x USB 2.0 • Display Out: 1 x DisplayPort, 1 x HDMI, 1 x D-Sub • VRM: Hybrid 6+2+1 phase solution • Lighting: 2 x ARGB Gen2 headers, 1 x RGB header • Warranty: 3 Years
Datasheet
| Memory Type | DDR4 |
|---|---|
| Warranty | 3 Years |
| Form Factor | mATX |
| Chipset | B760 |
| Socket | LGA1700 |
| CPU Type | 14th Gen,13th Gen,12th Gen,Pentium,Celeron |
| Max Memory | 64 GB |
| Memory Speed | up to 5333+ |
| Platform | INTEL |
| Graphics Port | 1x DisplayPort,1x HDMI, 1 x D-Sub |
| Memory Feature | Support for DDR4 5333(O.C.)/ 5133(O.C.)/ 5000(O.C.)/ 4933(O.C.)/ 4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/ 4266(O.C.)/ 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3800(O.C.)/ 3733(O.C.)/ 3666(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3333(O.C.)/ 3300(O.C.)/ 3200/ 3000/ 2933/ 2666/ 2400/ 2133 MT/s memory modules2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memoryDual channel memory architectureSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modulesSupport for Extreme Memory Profile (XMP) memory modules(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE\'s website for more information.) |
| Expansion Slots | CPU: – 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 * The PCIEX16 slot can only support a graphics card or an NVMe SSD. Chipset: – 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 |
| Channel Supported | Dual Channel |
| Wireless Networking | Wi-Fi,Bluetooth 5.0 |
| Back Panel I/O Ports | 2 x USB 2.0/1.1 ports1 x PS/2 keyboard/mouse port2 x antenna connectors (1T1R)1 x D-Sub port (Note)1 x HDMI port (Note)1 x DisplayPort (Note)3 x USB 3.2 Gen 1 ports1 x USB Type-C® port, with USB 3.2 Gen 1 support1 x RJ-45 port3 x audio jacks (Note) Actual support may vary by CPU |
| Internal I/O Connector | 1 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x CPU fan header3 x system fan headers2 x addressable RGB Gen2 LED strip headers1 x RGB LED strip header2 x M.2 Socket 3 connectors4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x S/PDIF Out header1 x USB 3.2 Gen 1 header2 x USB 2.0/1.1 headers1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)1 x serial port header1 x Q-Flash Plus button1 x reset jumper1 x Clear CMOS jumper |
