Gigabyte GeForce RTX 4060 Gaming OC 8GB GDDR6 Graphics Card

The Gigabyte GeForce RTX 4060 Gaming OC 8GB is a mid-range discrete graphics card built on NVIDIA's Ada Lovelace architecture, designed to deliver a strong 1080p and entry-level 1440p gaming experience. At its core sits the GeForce RTX 4060 GPU with 3072 CUDA cores running at a factory-overclocked boost clock of 2550 MHz — an uplift over the reference specification of 2460 MHz — giving you extra headroom straight out of the box without manual tuning. The card carries 8 GB of GDDR6 memory connected via a 128-bit interface at 17 Gbps effective bandwidth, a configuration well suited for the resolutions and texture quality the RTX 4060 targets. Fourth-generation Tensor Cores enable NVIDIA DLSS 3 Frame Generation, allowing the GPU to reconstruct intermediate frames and multiply perceived frame rates in supported titles. Third-generation RT Cores handle real-time ray tracing workloads, and support for DirectX 12 Ultimate ensures compatibility with all current and upcoming hardware-accelerated graphics features including mesh shaders and variable-rate shading. OpenGL 4.6 is also supported for professional and legacy workloads. GIGABYTE's WINDFORCE triple-fan cooling system uses three dedicated fans to draw heat away from the GPU die and VRAM, helping maintain stable clock speeds and lower operating temperatures during extended gaming sessions. A Dual BIOS switch is included, giving users a hardware-level backup mode should the primary firmware ever need recovery. A metal backplate adds structural rigidity and contributes to heat dissipation from the rear PCB surface. Connectivity covers up to four displays simultaneously, with outputs including HDMI and DisplayPort. The card draws power through a single 8-pin connector and requires a minimum 550 W power supply unit. It connects to the system via a PCIe 4.0 slot, ensuring backward compatibility with PCIe 3.0 motherboards while delivering full bandwidth on current-generation platforms. Maximum supported resolution is 7680 × 4320 (8K). Verifiable Specifications: • GPU Architecture: Ada Lovelace (NVIDIA GeForce RTX 4060) • CUDA Cores: 3072 • Boost Clock: 2550 MHz (Reference: 2460 MHz) • Memory: 8 GB GDDR6 • Memory Interface: 128-bit • Memory Speed: 17 Gbps • PCI Express: 4.0 • DirectX: 12 Ultimate | OpenGL: 4.6 • Display Outputs: HDMI + DisplayPort (up to 4 displays) • Power Connector: 1 × 8-pin • Recommended PSU: 550 W • Max Resolution: 7680 × 4320 • Cooling: WINDFORCE Triple Fan • BIOS: Dual BIOS Protection • Warranty: 3 Years • SKU: GV-N4060GAMING-OC-8GD
