MPN GIGABYTE-RTX-5060-AERO-OC-8GB · Brand GIGABYTE
Features of GIGABYTE Geforce RTX 5060 AERO OC White 8GB NVIDIA Graphic Card Powered by the NVIDIA Blackwell architecture and DLSS 4 Powered by GeForce RTX™ 5060 Integrated with 8GB GDDR7 128bit memory interface WINDFORCE cooling system Hawk fan Server-grade Thermal conductive gel RGB Lighting Dual BIOS (Performance / Silent) Reinforced structure The Ultimate Platform for Gamers and Creators Fifth-Gen Tensor Cores Max AI performance with FP4 and DLSS 4 New Streaming Multiprocessors Optimized for
Inclusive of GST · GST invoice available
Max AI performance with FP4 and DLSS 4
Optimized for neural shaders
Built for Mega Geometry
The WINDFORCE cooling system delivers exceptional thermal performance through a combination of cutting-edge technologies. It features server-grade thermal conductive gel, innovative Hawk fans with alternate spinning, composite copper heat pipes, a copper plate, 3D active fans, and screen cooling.
The Hawk Fan features a unique blade design inspired by the aerodynamics of an eagle's wing. This design reduces air resistance and noise levels, resulting in up to a 53.6% increase in air pressure and a 12.5% increase in air volume without compromising acoustics.
Reduce the turbulence of adjacent fans and increase airflow pressure.
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.
To enhance product quality and reliability, we have introduced server-grade thermal conductive gel for cooling critical components such as VRAM and MOSFETs. This highly deformable, non-fluid gel provides optimal contact for uneven surface and effectively resists deformation from transport or long-term use, unlike traditional thermal pads.
The copper plate directly contacts the GPU, coupled with the composite copper heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.
Extended heatsink allows air to pass through, providing better heat dissipation.
Drawing inspiration from water, the back panel's ripples evoke flowing water, with mirrored, frosted, and light elements reflecting the water's shimmering surface. Metal craftsmanship refines the texture, while teal and iridescent hues accentuate the serene lake. The fan's rotation creates expanding ripples, infusing natural movement into the details.
With 16.7M customizable color options and numerous lighting effects, you can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.
The reinforced metal backplate, securely fastened to the I/O bracket, provides exceptional structural integrity.
The factory default setting is Performance mode, which provides users with the best performance. However, switching to Silent mode will enjoy a quieter experience.
When experiencing any power supply abnormality, the indicator will alert gamers by flashing light.
| Graphics Processing | GV-N5060AERO-OC-8GD |
| Core Clock | 2595 MHz (Reference card: 2497 MHz) |
| CUDA® Cores | 3840 |
| Memory Clock | 28 Gbps |
| Memory Size | 8GB |
| Memory Type | GDDR7 |
| Memory Bus | 128 bit |
| Card Bus | PCI-E 5.0 |
| Digital max resolution | 7680x4320 |
| Multi-view | 4 |
| Card size | L=281 W=117 H=40 |
| PCB Form | ATX |
| DirectX | DirectX 12 API |
| OpenGL | 4.6 |
| Recommended PSU | 500W |
| Power Connectors | 8 Pin*1 |
| Output | DisplayPort 2.1b *3 HDMI 2.1b *1 |
| Accessories | Quick guide |
| Opengl | 4.6 |
|---|---|
| Output | DisplayPort 2.1b *3 HDMI 2.1b *1 |
| Directx | DirectX 12 API |
| Card Bus | PCI-E 5.0 |
| Pcb Form | ATX |
| Card Size | L=281 W=117 H=40 |
| Core Clock | 2595 MHz (Reference card : 2497 MHz) |
| Memory Bus | 128 bit |
| Multi-View | 4 |
| Accessories | Quick guide |
| Cuda® Cores | 3840 |
| Power Connectors | 8 Pin*1 |
| Graphics Processing | GV-N5060AERO-OC-8GD |
| Digital Max Resolution | 7680×4320 |
| Memory Type | GDDR7 |
| Memory Size | 8GB |
| Memory Clock | 28 Gbps |
| Recommended PSU | 500W |
