GIGABYTE H810M Gaming Wifi6 DDR5 Intel Motherboard
MPN GIGABYTE-H810M-GAMING-DDR5 · Brand GIGABYTE · mATX
The GIGABYTE H810M Gaming WiFi 6 DDR5 is a Micro ATX motherboard for Intel Core Ultra Series 2 processors on LGA 1851, featuring DDR5 memory support up to 128 GB, PCIe 4.0 M.2 storage, 2.5 GbE LAN, and Wi-Fi 6 connectivity
Inclusive of GST · GST invoice available
Overview
The GIGABYTE H810M Gaming WiFi 6 DDR5 is a Micro ATX motherboard designed for Intel Core Ultra processors (Series 2) on the LGA 1851 socket. Powered by the Intel H810 chipset, it offers a compact yet feature-rich platform for gaming builds that demand modern connectivity, fast storage, and reliable power delivery. Memory support is handled by two DDR5 DIMM slots (288-pin) in a dual-channel configuration, accommodating up to 128 GB of system memory (64 GB per DIMM). The board supports DDR5 speeds of 5600 and 6400 MT/s and is compatible with ECC Un-buffered and non-ECC Un-buffered DIMM modules in 1Rx8, 2Rx8, and 1Rx16 configurations (ECC modules operate in non-ECC mode). For storage, the board provides one M.2 connector (Socket 3, M key, type 2280) supporting PCIe 4.0 x4/x2 NVMe SSDs, plus four SATA 6 Gb/s ports with RAID 0/1/5/10 support. A single PCIe 4.0 x16 slot accommodates a discrete graphics card or NVMe SSD, and one PCIe 3.0 x1 slot handles additional expansion cards. Networking is handled by integrated 2.5 Gbps LAN (RJ-45) alongside Wi-Fi 6 (802.11ax) and Bluetooth 5.3, enabled via the WIFI EZ-Plug antenna adapter. Rear I/O includes HDMI, DisplayPort, one USB 3.2 Gen 1 Type-A port, five USB 2.0/1.1 ports, a PS/2 keyboard/mouse port, and three audio jacks supporting 7.1-channel audio. Onboard headers include a USB Type-C header (USB 3.2 Gen 1), one USB 3.2 Gen 1 header, and two USB 2.0/1.1 headers. Thermal management is addressed through VRM heatsinks, an M.2 Thermal Guard to prevent SSD throttling, and the Smart Fan 6 fan control system (one CPU fan header and two system fan headers). Two addressable RGB Gen2 LED strip headers enable RGB customisation via GIGABYTE RGB Fusion software. Assembly-friendly features include PCIe EZ-Latch for tool-free graphics card removal and M.2 EZ-Latch Plus for screwless M.2 SSD installation. The UEFI BIOS (AMI, 256 Mbit flash) supports Q-Flash for firmware updates and multi-theme skins. Software support includes GIGABYTE Control Center (GCC), Smart Backup, and HWiNFO integration. Verified Specifications: - Form Factor: Micro ATX | Dimensions: 9.6" x 8.5" - CPU Socket: LGA 1851 | Chipset: Intel H810 - Compatible CPUs: Intel Core Ultra Series 2 - Memory: 2x DDR5 DIMM (288-pin), up to 128 GB, dual-channel, DDR5 6400/5600 MT/s - M.2: 1x PCIe 4.0 x4 (type 2280) - SATA: 4x SATA 6 Gb/s | RAID: 0/1/5/10 - PCIe Slots: 1x PCIe 4.0 x16, 1x PCIe 3.0 x1 - LAN: 2.5 Gbps | Wireless: Wi-Fi 6 (802.11ax) | Bluetooth: 5.3 - Audio: 7.1-channel - Rear USB: 1x USB 3.2 Gen 1, 5x USB 2.0/1.1 - Display Output: 1x HDMI, 1x DisplayPort - Power: 24-pin ATX + 8-pin ATX 12V
Datasheet
| Form Factor | mATX |
|---|---|
| Chipset | INTEL H810 |
| CPU Type | Intel Core Ultra Processors (Series 2) |
| M.2 | 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) |
| Model | H810M GAMING WIFI6 |
| Features | Support for GIGABYTE Control Center (GCC) Support for Q-Flash Support for Smart Backup |
| Bluetooth | BLUETOOTH 5.3 |
| Power Pin | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector |
| Sata Raid | 0/1/5/10 |
| Sata 6Gb/S | 4 x SATA 6Gb/s |
| Onboard USB | 1 x USB Type-C header, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers |
| Bios Feature | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Wireless Lan | Wi-Fi 802.11 ax |
| Max Lan Speed | 2.5Gbps |
| Audio Channels | 7.1 Channels |
| Back I/O Ports | 1 x PS/2 keyboard/mouse port 1 x HDMI port (Note) 1 x DisplayPort (Note) 1 x USB 3.2 Gen 1 port 5 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks |
| Memory Feature | 2 x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity) of system memory Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules |
| Pci Express X1 | 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 (PCIEX1) |
| CPU Socket Type | LGA 1851 |
| Memory Standard | Support for DDR5 6400/5600 |
| Other Connectors | 1 x CPU fan header 2 x system fan headers 2 x addressable RGB Gen2 LED strip headers 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only) 1 x serial port header 1 x Clear CMOS jumper |
| Channel Supported | Dual Channel |
| Dimensions (W X L) | 9.6" x 8.5" |
| Pci Express 4.0 X16 | 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) * The PCIEX16 slot can only support a graphics card or an NVMe SSD |
| Number Of Memory Slots | 2x288pin (DDR5) |
| Maximum Memory Supported | 128GB |
