GIGABYTE RTX 5060 Ti Eagle Max OC 16GB GDDR7 Graphics Card

The GIGABYTE RTX 5060 Ti Eagle Max OC (model GV-N506TEAGLEMAX-OC-16GD) brings NVIDIA's Blackwell architecture to the mainstream segment, pairing a 4608-core CUDA engine with a generous 16 GB GDDR7 framebuffer over a 128-bit memory interface. The GPU's boost clock is rated at 2617 MHz — 45 MHz above the 2572 MHz NVIDIA reference figure — making this a factory-overclocked variant right out of the box. Memory bandwidth reaches an effective 28 Gbps, and the card connects via PCIe 5.0, ensuring it is compatible with current and next-generation platforms without a bandwidth bottleneck. Display output is flexible, supporting up to four simultaneous monitors at resolutions up to 7680 × 4320 (8K) through a combination of HDMI and DisplayPort connectors, with DirectX 12 and OpenGL 4.6 API support. Cooling is handled by GIGABYTE's WINDFORCE system, centred on three Hawk fans whose blade profiles are designed to reduce air resistance relative to conventional blades, while alternate-spinning adjacent fans cancel out turbulence and lateral airflow. Composite copper heat pipes transfer heat from a copper baseplate that directly contacts the GPU die, routing it across a multi-segment aluminium fin stack with a screen-cooling pass-through zone for improved dissipation. In place of conventional thermal pads, GIGABYTE uses a server-grade thermal conductive gel on the VRAM and MOSFET regions; the gel's high conformability is said to maintain consistent contact across uneven surfaces and to resist deformation over time. A reinforced metal backplate with a bent edge anchors to the I/O bracket for structural rigidity across the card's length. The Eagle Max's aesthetic draws on aerospace and sci-fi design language — curved contours, segmented surface lines, and bold frontal identity elements that align visually with GIGABYTE's Eagle-series motherboard line for a cohesive build aesthetic. The card carries a 3-year warranty and requires a 650 W or higher power supply. A single 8-pin power connector feeds the card. Verifiable specifications: • GPU: NVIDIA GeForce RTX 5060 Ti (Blackwell architecture) • CUDA cores: 4608 • Boost clock: 2617 MHz (Reference: 2572 MHz) • Memory: 16 GB GDDR7, 128-bit interface, 28 Gbps effective • PCIe: 5.0 • Max resolution: 7680 × 4320 • Max simultaneous displays: 4 • API: DirectX 12, OpenGL 4.6 • Cooling: WINDFORCE triple-fan (Hawk fans) • Power connector: 1 × 8-pin • Recommended PSU: 650 W • Warranty: 3 years • DLSS: 4.5
