Gigabyte RX 9060 XT Gaming OC 16GB GDDR6 Graphics Card
MPN GV-R9060XTGAMING-OC-16GD · Brand GIGABYTE
Gigabyte's Radeon RX 9060 XT Gaming OC delivers 16 GB GDDR6 memory, 2048 stream processors, and a factory boost clock of up to 3320 MHz, cooled by the WINDFORCE triple-fan system with PCIe 5.0 connectivity
Inclusive of GST · GST invoice available
Overview
The Gigabyte Radeon RX 9060 XT Gaming OC 16GB (GV-R9060XTGAMING-OC-16GD) is a mid-to-high-range discrete graphics card built on AMD's Radeon RX 9060 XT GPU. It pairs 2048 stream processors with a generous 16 GB of GDDR6 memory on a 128-bit interface, running at an effective speed of 20 Gbps. The factory-overclocked engine delivers a game clock of up to 2780 MHz and a boost clock of up to 3320 MHz — both comfortably above the reference card's 2530 MHz game clock and 3130 MHz boost — giving you tangible real-world headroom in demanding titles and creative workloads. Cooling is handled by GIGABYTE's WINDFORCE system, which combines three Hawk fans that alternate their spin direction to reduce turbulence, composite copper heat pipes, a direct-contact copper plate, and server-grade thermal conductive gel for consistent heat transfer from die to heatsink. A 3D active fan mode allows the fans to stop entirely under light loads, keeping the card silent during desktop use or light gaming. The exterior follows GIGABYTE's GAMING series design language — a multi-layered, mech-warrior-inspired shroud with distinct surface textures and a mechanical aesthetic. Integrated RGB lighting supports 16.7 million colour options and can be synchronised with other components through GIGABYTE CONTROL CENTER. A sliding side plate lets you personalise the look further, while a reinforced metal backplate bolted to the I/O bracket keeps the card rigid in the chassis. Connectivity runs over PCI Express 5.0 and power delivery requires a single 8-pin connector with a recommended PSU of 450 W. The card supports up to three simultaneous displays at resolutions up to 7680 × 4320 (8K) via its HDMI and DisplayPort outputs. API support covers DirectX 12 and OpenGL 4.6. GIGABYTE backs the card with a 3-year warranty. Verifiable specifications at a glance: • GPU: AMD Radeon RX 9060 XT | Stream Processors: 2048 • Memory: 16 GB GDDR6, 128-bit interface, 20 Gbps effective speed • Boost clock: up to 3320 MHz | Game clock: up to 2780 MHz • Interface: PCI Express 5.0 | Power connector: 1 × 8-pin • Recommended PSU: 450 W | Max resolution: 7680 × 4320 • Max displays: 3 | DirectX: 12 | OpenGL: 4.6 • Warranty: 3 years
Datasheet
| Memory Type | GDDR6 |
|---|---|
| Warranty | 3 Years |
| Chipset | AMD RADEON |
| Memory Size | 16 GB |
| GPU | RX 9060 XT |
| Memory Clock | 20 Gbps |
| Recommended PSU | 450W |
| Resolution | 7680 x 4320 |
| Model | GV-R9060XTGAMING-OC-16GD |
| Ports | HDMI,DisplayPort |
| Cooler | Triple Fan |
| Note** | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only |
| Opengl | 4.6 |
| Directx | 12 API |
| Pci Express | 5.0 |
| Engine Clock | Boost Clock : up to 3320 MHz (Reference card: 3130 MHz) Game Clock : up to 2780 MHz (Reference card: 2530 MHz) |
| Memory Interface | 128-BIT |
| Power Connectors | 1 x 8-pin |
| Max Display Support | 3 |
| GPU Core (Cuda Core) | 2048 |
