Gigabyte UD750GM PG5 V2 Gold 750 Watt ATX 3.1 Fully Modular Smps

The GIGABYTE UD750GM PG5 V2 is a 750-watt fully modular power supply built on the ATX 3.1 standard, designed to meet the power delivery requirements of modern high-performance PC builds. With native PCIe Gen 5.1 readiness and a 16-pin connector capable of delivering up to 600W, it is compatible with graphics cards such as the GeForce RTX 50 Series and other next-generation GPUs. At the heart of this PSU is an 80 PLUS Gold certification, which means it delivers 90% efficiency at 50% load, translating to less wasted heat, lower energy costs, and quieter operation compared to lower-rated units. It also carries a Cybenetics Platinum efficiency rating, adding independent verification of its power efficiency credentials. All internal capacitors are sourced from Japanese manufacturers, a build quality detail that supports long-term reliability and stable voltage regulation throughout the unit's lifespan. Thermal management is handled by a 120mm hydraulic bearing (HYB) fan that operates on a smart fan curve — remaining completely silent when the system is idle or under 20% load, and ramping up only when thermal output demands it. The single +12V rail design simplifies cable management decisions and ensures maximum compatibility across CPUs, GPUs, and storage devices. The fully modular cable system means only the cables your build actually needs are connected, reducing internal clutter and improving chassis airflow. Comprehensive protection circuitry covers over-voltage (OVP), over-power (OPP), short-circuit (SCP), under-voltage (UVP), over-current (OCP), over-temperature (OTP), no-load operation (NLO), and surge/inrush protection (SIP). The compact 140mm depth makes it compatible with space-constrained ATX and mATX chassis. Verified Specifications: - Wattage: 750W - ATX Standard: ATX 3.1 / PCIe Gen 5.1 ready - Efficiency: 80 PLUS Gold (90% at 50% load); Cybenetics Platinum rated - Fan: 120mm hydraulic bearing (HYB), smart fan control - Modularity: Fully modular - +12V Rail: Single rail, 83.3A / 1000W combined - +3.3V / +5V: 25A each, 125W combined - -12V: 0.3A / 3.6W - +5Vsb: 3A / 15W - SATA Connectors: 8 - PCIe 6+2 Pin Connectors: 4 - Peripheral (4-Pin): 3 - Input Voltage: 100–240V AC (global); 200–240V AC (China) - Active PFC: Yes - Depth: 140mm - Warranty: 10 years - SKU: GP-UD750GM-PG5-V2
