INNO3D RTX 5060 Ti Twin X2 OC 8GB GDDR7 Graphics Card

The INNO3D GeForce RTX 5060 Ti Twin X2 OC is a compact, dual-slot graphics card built on NVIDIA's Blackwell architecture, making it a strong choice for small-form-factor (SFF), Micro-ATX, and Mini-ITX builds that demand modern GPU performance without sacrificing chassis space. Despite its restrained physical footprint, this card delivers a full complement of next-generation features drawn directly from the RTX 50 series platform. At the heart of the Twin X2 OC is NVIDIA's Blackwell GPU die, providing 4,608 CUDA cores and a factory-overclocked boost clock of 2,602 MHz, with a base clock of 2,325 MHz. The 8 GB of GDDR7 memory operates at 28 Gbps across a 128-bit interface, delivering substantial memory bandwidth relative to its bus width. The card connects via PCIe 5.0 and can drive up to four displays simultaneously at resolutions up to 7,680 × 4,320 (8K), with output options including HDMI and DisplayPort. Power draw is managed through a single 8-pin connector, and INNO3D recommends a 650 W system PSU. The Twin X2 OC's cooling solution uses two 88 mm scythe-blade fans with detachable blades for maintenance, backed by four nickel-plated composite heatpipes and a copper base plate that makes direct contact with the GPU die to absorb heat quickly. A separate aluminium heat spreader covers the GDDR7 memory modules, and optimised fin pitch and spacing promote airflow through the heatsink stack. A metal backplate adds structural rigidity. The overall design occupies exactly two expansion slots. On the software and API side, the card supports DirectX 12 Ultimate, OpenGL 4.6, NVIDIA DLSS 4 (including Multi Frame Generation and enhanced Ray Reconstruction and Super Resolution via fifth-generation Tensor Cores), and NVIDIA Reflex 2 with Frame Warp for reduced system latency in competitive titles. NVIDIA Studio driver support is included for creative workloads such as video editing, 3D rendering, and graphic design. Key Verified Specifications: • GPU: NVIDIA GeForce RTX 5060 Ti (Blackwell) • CUDA Cores: 4,608 • Memory: 8 GB GDDR7 • Memory Interface: 128-bit • Memory Speed: 28 Gbps • Boost Clock: 2,602 MHz | Base Clock: 2,325 MHz • PCIe: 5.0 • Display Outputs: HDMI + DisplayPort (up to 4 displays) • Max Resolution: 7,680 × 4,320 • Power Connector: 1 × 8-pin • Recommended PSU: 650 W • Slot Width: 2-slot • DirectX: 12 Ultimate | OpenGL: 4.6 • Warranty: 3 Years (INNO3D India) • SKU: N506T2-08D7X-193075N
