INTEL Core i5 11400 11th Generation Processor ( 4.4 GHz / 6 Cores / 12 Threads )
MPN INTEL-I5-11400 · Brand Intel
Features Of INTEL Core i5 11400 11th Generation Processor Intel Intel I511th Generation Series LGA1200 Socket 6 Cores, 12 Threads Base Clock 2.6GHz, Max Boost Clock Up to 4.4GHz of Intel CPU Cache 12MB Cooler & Heatsink Included Intel UHD Graphics 730 Graphics Max Dynamic Frequency 1.30 GHz 4K Support at 60Hz Intel Core i5 11th Generation 2.60 GHz processor offers hyper-threading architecture that delivers high performance for demanding applications with improved onboard graphics and turbo b
Inclusive of GST · GST invoice available
Overview
Features Of INTEL Core i5 11400 11th Generation Processor
- Intel Intel I511th Generation Series
- LGA1200 Socket
- 6 Cores, 12 Threads
- Base Clock 2.6GHz, Max Boost Clock Up to 4.4GHz of Intel CPU
- Cache 12MB
- Cooler & Heatsink Included
- Intel UHD Graphics 730
- Graphics Max Dynamic Frequency 1.30 GHz
- 4K Support at 60Hz
Intel Core i5 11th Generation 2.60 GHz processor offers hyper-threading architecture that delivers high performance for demanding applications with improved onboard graphics and turbo boost
The Socket LGA-1200 socket allows processor to be placed on the PCB without soldering
14 nm design offers great efficiency for computing, delivers nimble processing with balanced cost, performance, and power
12 MB of L3 cache rapidly retrieves the most used data available to improve system performance, Max Turbo Frequency 4.40 GHz
Built-in Intel UHD Graphics 730 controller for improved graphics and visual quality. Supports up to 3 monitors.
Specifications Of INTEL Core i5 11400 11th Generation Processor
| Product Code | BX8070811400 |
| Product Collection | 11th Generation Intel® Core™ i5 Processors |
| Code Name | Products formerly Rocket Lake |
| Vertical Segment | Desktop |
| Processor Number | i5-11400 |
| Lithography | 14 nm |
| Use Conditions | PC/Client/Tablet |
| Performance Specifications | |
| Cores | 6 |
| Threads | 12 |
| Processor Base Frequency | 2.60 GHz |
| Max Turbo Frequency | 4.40 GHz |
| Cache | 12 MB Intel® Smart Cache |
| Bus Speed | 8 GT/s |
| Intel® Turbo Boost Technology 2.0 Frequency | 4.40 GHz |
| TDP | 65 W |
| Supplemental Information | |
| Embedded Options Available | No |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 128 GB |
| Memory Types | DDR4-3200 |
| Max Memory Channels | 2 |
| Max Memory Bandwidth | 50.0 GB/s |
| ECC Memory Supported | No |
| Processor Graphics | |
| Processor Graphics | Intel® UHD Graphics 730 |
| Graphics Base Frequency | 350 MHz |
| Graphics Max Dynamic Frequency | 1.30 GHz |
| Graphics Video Max Memory | 64 GB |
| Execution Unit | 24 |
| 4K Support | Yes, at 60Hz |
| Max Resolution (HDMI) | 4096x2160@60Hz |
| Max Resolution (DP) | 5120x3200@60Hz |
| Max Resolution (eDP - Integrated Flat Panel) | 5120x3200@60Hz |
| DirectX Support | 12.1 |
| OpenGL Support | 4.5 |
| Intel® Quick Sync Video | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Clear Video HD Technology | Yes |
| Intel® Clear Video Technology | Yes |
| Displays Supported | 3 |
| Device ID | 0x4C8B |
| Open CL Support | 3 |
| Expansion Options | |
| Scalability | 1S Only |
| PCI Express Revision | 4 |
| PCI Express Configurations | Up to 1x16+1x4, 2x8+1x4, 1x8+3x4 |
| Max PCI Express Lanes | 20 |
| Package Specifications | |
| Socket Supported | FCLGA1200 |
| Max CPU Configuration | 1 |
| Thermal Solution Specification | PCG 2019C |
| TJUNCTION | 100°C |
| Package Size | 37.5 mm x 37.5 mm |
| Advanced Technologies | |
| Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
| Intel® Optane™ Memory Supported | Yes |
| Intel® Thermal Velocity Boost | No |
| Intel® Turbo Boost Max Technology 3.0 | No |
| Intel® Turbo Boost Technology | 2 |
| Intel vPro® Platform Eligibility | No |
| Intel® Hyper-Threading Technology | Yes |
| Intel® Virtualization Technology (VT-x) | Yes |
| ntel® Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
| Intel® 64 | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2, Intel® AVX-512 |
| Idle States | Yes |
| Enhanced Intel SpeedStep® Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Identity Protection Technology | Yes |
| Intel® Stable Image Platform Program (SIPP) | No |
| Intel® Gaussian and Neural Accelerator 2.0 | Yes |
| Security & Reliability | |
| Intel® AES New Instructions | Yes |
| Secure Key | Yes |
| Intel® Software Guard Extensions (Intel® SGX) | No |
| Intel® OS Guard | Yes |
| Intel® Trusted Execution Technology | No |
| Execute Disable Bit | Yes |
| Intel® Boot Guard | Yes |
| Warranty | 3 Years |
| Note | ***Features, Price and Specifications are subject to change without notice. |
Datasheet
| Warranty | 3 Years |
|---|---|
| Cores | 6 |
| Threads | 12 |
| TDP | 65 W |
| Cache | 12 MB Intel® Smart Cache |
| Bus Speed | 8 GT/s |
| Code Name | Products formerly Rocket Lake |
| Device Id | 0x4C8B |
| Tjunction | 100°C |
| 4K Support | Yes, at 60Hz |
| Intel® 64 | Yes |
| Secure Key | Yes |
| Idle States | Yes |
| Lithography | 14 nm |
| Scalability | 1S Only |
| Memory Types | DDR4-3200 |
| Package Size | 37.5 mm x 37.5 mm |
| Product Code | BX8070811400 |
| Execution Unit | 24 |
| Opengl Support | 4.5 |
| Use Conditions | PC/Client/Tablet |
| Directx Support | 12.1 |
| Instruction Set | 64-bit |
| Open Cl Support | 3 |
| Intel® Os Guard | Yes |
| Processor Number | i5-11400 |
| Socket Supported | FCLGA1200 |
| Vertical Segment | Desktop |
| Displays Supported | 3 |
| Intel® Boot Guard | Yes |
| Processor Graphics | Intel® UHD Graphics 730 |
| Product Collection | 11th Generation Intel® Core™ i5 Processors |
| Execute Disable Bit | Yes |
| Max Memory Channels | 2 |
| Max Resolution (Dp) | 5120×3200@60Hz |
| Max Turbo Frequency | 4.40 GHz |
| ECC Memory Supported | No |
| Max Memory Bandwidth | 50.0 GB/s |
| Pci Express Revision | 4 |
| Max CPU Configuration | 1 |
| Max Pci Express Lanes | 20 |
| Max Resolution (Hdmi) | 4096×2160@60Hz |
| Graphics Base Frequency | 350 MHz |
| Intel® Quick Sync Video | Yes |
| Processor Base Frequency | 2.60 GHz |
| Graphics Video Max Memory | 64 GB |
| Embedded Options Available | No |
| Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2, Intel® AVX-512 |
| Pci Express Configurations | Up to 1×16+1×4, 2×8+1×4, 1×8+3×4 |
| Intel® Aes New Instructions | Yes |
| Graphics Max Dynamic Frequency | 1.30 GHz |
| Intel® Clear Video Technology | Yes |
| Intel® Intru™ 3D Technology | Yes |
| Intel® Thermal Velocity Boost | No |
| Intel® Turbo Boost Technology | 2 |
| Thermal Solution Specification | PCG 2019C |
| Thermal Monitoring Technologies | Yes |
| Intel Vpro® Platform Eligibility | No |
| Intel® Clear Video Hd Technology | Yes |
| Intel® Hyper-Threading Technology | Yes |
| Intel® Optane™ Memory Supported | Yes |
| Intel® Trusted Execution Technology | No |
| Enhanced Intel Speedstep® Technology | Yes |
| Intel® Identity Protection Technology | Yes |
| Intel® Turbo Boost Max Technology 3.0 | No |
| Intel® Virtualization Technology (Vt-X) | Yes |
| Max Memory Size (Dependent On Memory Type) | 128 GB |
| Intel® Gaussian And Neural Accelerator 2.0 | Yes |
| Intel® Stable Image Platform Program (Sipp) | No |
| Intel® Turbo Boost Technology 2.0 Frequency | 4.40 GHz |
| Intel® Vt-X With Extended Page Tables (Ept) | Yes |
| Max Resolution (Edp - Integrated Flat Panel) | 5120×3200@60Hz |
| Intel® Deep Learning Boost (Intel® Dl Boost) | Yes |
| Intel® Software Guard Extensions (Intel® Sgx) | No |
| Ntel® Virtualization Technology For Directed I/O (Vt-D) | Yes |
