Intel Core i5-14500 Processor

The Intel Core i5-14500 is a 14th-generation desktop processor built on the Raptor Lake architecture, using Intel’s Intel 7 process node. It is designed for the LGA1700 socket, making it compatible with 600- and 700-series Intel motherboards. The i5-14500 features a hybrid core design with 6 Performance-cores and 8 Efficient-cores for a total of 14 cores and 20 threads. Performance-cores operate at a base frequency of 2.6 GHz and can boost up to 5.0 GHz, while Efficient-cores have a base frequency of 1.9 GHz and a max turbo of 3.7 GHz. The processor carries a 24 MB Intel Smart Cache and 11.5 MB of total L2 cache, providing ample low-latency storage for frequent workloads. With a processor base power (TDP) of 65 W and a maximum turbo power of 154 W, the i5-14500 scales its power draw according to workload demands, aided by Enhanced Intel SpeedStep Technology and Intel Speed Shift Technology for responsive dynamic frequency management. Intel Turbo Boost Technology 2.0 and Hyper-Threading Technology are both supported. Memory support extends to DDR5 at up to 4800 MT/s and DDR4 at up to 3200 MT/s across 2 memory channels, with a maximum supported memory capacity of 192 GB. ECC memory is supported, making this chip viable for workstation deployments as well as desktop PC builds. Maximum memory bandwidth reaches 76.8 GB/s. The processor integrates Intel UHD Graphics 770 with 32 Execution Units, reaching a maximum dynamic frequency of 1.55 GHz. Display output options include HDMI 2.1 (up to 4096×2160 @ 60 Hz), DisplayPort 1.4a (up to 7680×4320 @ 60 Hz), and eDP 1.4b (up to 5120×3200 @ 120 Hz), with support for up to 4 simultaneous displays. DirectX 12, OpenGL 4.5, and OpenCL 3.0 are all supported. Connectivity is delivered via DMI 4.0 with 8 lanes and up to 20 PCIe lanes supporting PCIe 5.0 and PCIe 4.0 configurations. The package size is 45.0 mm × 37.5 mm and the processor operates within a maximum junction temperature (TJUNCTION) of 100 °C. A boxed unit includes a CPU cooler (Thermal Solution Specification: PCG 2020C). On the AI and advanced compute side, Intel Gaussian & Neural Accelerator 3.0 and Intel Deep Learning Boost (DL Boost) on CPU are included. Intel Thread Director assists the operating system in scheduling tasks optimally across Performance and Efficient cores. Security features include Intel Control-Flow Enforcement Technology, AES New Instructions, Secure Key, OS Guard, Boot Guard, Mode-based Execute Control (MBEC), Execute Disable Bit, and full virtualisation support via VT-x, VT-d, and VT-x with Extended Page Tables (EPT). Verified Specifications: • Model: Intel Core i5-14500 (SKU BX8071514500) • Architecture: Raptor Lake (14th Gen), Intel 7 process • Cores / Threads: 14 (6P + 8E) / 20 • P-core Base / Boost: 2.6 GHz / 5.0 GHz • E-core Base / Boost: 1.9 GHz / 3.7 GHz • Cache: 24 MB Intel Smart Cache + 11.5 MB L2 • TDP (Base / Turbo): 65 W / 154 W • Socket: FCLGA1700 • Memory: DDR5-4800, DDR4-3200; max 192 GB; 2-channel; ECC supported • Integrated GPU: Intel UHD Graphics 770 (32 EU, 1.55 GHz) • PCIe: 5.0 + 4.0, up to 20 lanes • Warranty: 3 Years
