INTEL Core i7 14700KF 14th Generation Processor ( 5.6 GHz / 20 Cores / 28 Threads )

The Intel Core i7-14700KF is a 14th Generation desktop processor built on Intel’s Raptor Lake architecture and manufactured on the Intel 7 process node. It slots into the LGA1700 socket, making it compatible with both 600-series and 700-series motherboards, and supports DDR4 memory at up to 3200 MT/s or DDR5 memory at up to 5600 MT/s — giving builders flexibility to work with existing platforms or upgrade to the latest memory standard. At its core the i7-14700KF deploys a hybrid architecture comprising 8 Performance-cores and 12 Efficient-cores for a total of 20 cores and 28 threads. The Performance-cores reach a base frequency of 3.4 GHz and boost up to 5.5 GHz, while the Efficient-cores run a 2.5 GHz base and boost to 4.3 GHz. The overall Max Turbo Frequency via Intel Turbo Boost Max Technology 3.0 is 5.6 GHz. Intel Thread Director works alongside the operating system to assign tasks intelligently between Performance and Efficient cores, helping maintain smooth gameplay while background workloads such as streaming or encoding run concurrently. The processor carries 33 MB of Intel Smart Cache (L3) plus 28 MB of total L2 cache. This expanded cache pool helps sustain consistent frame rates and reduces latency in data-intensive workloads. The KF designation means the chip is unlocked for overclocking but ships without integrated graphics, making it a natural partner for a dedicated GPU. Intel Extreme Tuning Utility (XTU) allows frequency and voltage adjustments at the user’s discretion. Connectivity is handled through PCIe 5.0 and PCIe 4.0 lanes (up to 20 PCIe lanes total) and DMI 4 with 8 lanes to the chipset. Maximum supported memory reaches 192 GB across 2 channels, with a peak bandwidth of 89.6 GB/s. The processor’s Processor Base Power is 125 W, rising to a Maximum Turbo Power of 253 W, so a capable cooler and PSU are recommended. The thermal junction limit is 100 °C. On the AI and acceleration side, the i7-14700KF includes Intel Gaussian and Neural Accelerator 3.0 and Intel Deep Learning Boost on the CPU, supporting productivity, content-creation, and AI-assisted workflows. Security features include Intel Boot Guard, Control-Flow Enforcement Technology, AES-NI, OS Guard, Execute Disable Bit, VT-x, VT-d, and Secure Key. Verified Specifications: – Processor Number: i7-14700KF | Product Code: BX8071514700KF – Cores / Threads: 20 (8P + 12E) / 28 – Max Turbo Frequency: 5.6 GHz | P-core Base: 3.4 GHz | E-core Base: 2.5 GHz – L3 Cache: 33 MB Intel Smart Cache | L2 Cache: 28 MB – Socket: FCLGA1700 | Lithography: Intel 7 – Memory: DDR5-5600 / DDR4-3200 | Max: 192 GB | Bandwidth: 89.6 GB/s – PCIe: 5.0 + 4.0, up to 20 lanes | DMI: Rev 4, 8 lanes – TDP (Base Power): 125 W | Max Turbo Power: 253 W – Launch: Q4 2023
