Lian Li Hydroshift II LCD-S 360 CL RGB CPU Liquid Cooler

The Lian Li HydroShift II LCD-S 360 CL RGB is a 360 mm all-in-one liquid cooler that combines a sharp integrated display, a high-speed pump, and a clean cable routing system into a single premium cooling solution. It is designed for builders who want real-time system telemetry without sacrificing aesthetics. At the heart of the build is a 3.4-inch IPS LCD panel running at 480×480 resolution with 500 nits of peak brightness and a 60 Hz refresh rate. The display attaches via a magnetic pogo-pin connector, meaning it can be installed or removed after the system is assembled without powering down. Three control modes are available through Lian Li's L-Connect 3 software: Offline, Wireless, and USB Streaming, the last of which supports JPG and MP4 media uploads alongside customisable widgets. The pump has been upgraded to reach speeds between 1,600 and 3,200 RPM (±10%), delivering stronger flow while keeping noise at or below 28 dBA. The water block measures 91 × 99 × 62 mm. Cooling is handled by three UNI FAN CL Wireless fans, each measuring 124 × 120 × 28 mm and spinning between 0/200 and 2,100 RPM. Each fan delivers up to 72.7 CFM of airflow at up to 3.00 mmH₂O static pressure, with a rated noise level of 30 dBA. Fan bearings are Fluid Dynamic Bearing (FDB) type for long-term reliability. RGB illumination is integrated into both the light strips and fan blades, with independent effect control per zone via L-Connect 3. The aluminium radiator has been refined to 400 × 122 × 24 mm — thinner and shorter than previous generations — while Lian Li states it maintains broad compatibility with mainstream cases. Tubing length is 450/470 mm. USB power and data lines are embedded inside the sleeved tubing, eliminating visible front-facing cables. Pre-installed triple tube clips route the tubing along the radiator edge, and a removable sliding tube mount enables precise alignment with 140 mm fan brackets. For hidden-tube installations, the case top-mounting area should be at least 280 × 400 mm; a bracket clearance exceeding 55 mm is recommended. CPU socket compatibility covers Intel LGA1700 and LGA1851, as well as AMD AM4 and AM5, with an upgraded AM4/AM5 bracket designed for even contact pressure. The cooler ships with a redesigned mounting bracket and a cover piece that conceals screws for a cleaner finish. A cable organiser is included for managing extended tubing runs. If the motherboard cannot read pump RPM, Lian Li recommends connecting the 4-pin PWM header to a SATA power adapter. The 2-pin connector operates independently and requires no additional power connection. — Verified Specifications — Radiator: 400 × 122 × 24 mm, aluminium Pump speed: 1,600–3,200 RPM ±10% Pump noise: ≤28 dBA Water block: 91 × 99 × 62 mm LCD panel: 3.4″ IPS, 480×480, 500 nit, 60 Hz Fan size: 124 × 120 × 28 mm (×3) Fan speed: 0/200–2,100 RPM Fan airflow: 72.7 CFM Fan pressure: 3.00 mmH₂O Fan noise: 30 dBA Bearing: Fluid Dynamic Bearing (FDB) Tubing length: 450/470 mm Socket support: Intel LGA1700, LGA1851 / AMD AM4, AM5 Warranty: 6 years
