Msi MAG Forge 340R Airflow ARGB ATX Mid Tower Case
MPN MAG-FORGE-340R-AIRFLOW-BLACK · Brand MSI · ATX, mATX, Mini-ITX
The MSI MAG Forge 340R Airflow is an ATX mid-tower PC case featuring a mesh front panel, 4 pre-installed ARGB fans, 360mm AIO support, up to 390mm GPU clearance, and a 3mm tempered glass side panel
Inclusive of GST · GST invoice available
Overview
The MSI MAG Forge 340R Airflow is an ATX mid-tower chassis designed for builders who prioritise cooling performance and visual impact in equal measure. At its core, the case ships with four pre-installed fans, and the chassis accommodates up to 11 x 120mm fans in total, giving you ample headroom to build an aggressively cooled system without sourcing extra hardware immediately. The front panel is constructed with a mesh design that promotes unrestricted airflow into the chassis, feeding air directly to your components. Radiator support is generous: the case accepts up to a 360mm all-in-one liquid cooler, along with 280mm, 240mm, 140mm, and 120mm radiators at other mounting positions. The maximum GPU clearance of 390mm means current-generation and upcoming large graphics cards, including 50-series models mentioned in source documentation, will fit without modification. A 3mm tempered glass side panel runs the length of the chassis, making the ARGB lighting visible from outside. The lighting ecosystem integrates with MSI Mystic Light via the built-in daisy-chain connector, which reduces cable clutter and allows synchronised control directly through a compatible MSI motherboard. CPU coolers up to 160mm tall are supported. Storage flexibility is built in: configure the drive bays as up to three 2.5-inch SSDs, or mix one 2.5-inch SSD with two 3.5-inch hard drives. The I/O panel on the front includes a reset button, audio out, microphone in, and a USB Type-A port. Two USB 5Gbps (Type-A) ports are also present on the front panel. A magnetic dust filter covers the top vents for easy removal and cleaning without tools. Seven expansion slots accommodate multi-card or high-profile bracket configurations. The tool-free EZ-release side panel and unified front-panel cable connector are designed to simplify the build process, particularly when pairing with MSI motherboards. Verified Specifications: - Form Factor: ATX / M-ATX / M-ITX - Colour: Black - Pre-installed Fans: 4 - Maximum Fan Support: 11 x 120mm - Maximum Radiator Support: 360mm (also 280mm, 240mm, 140mm, 120mm) - Maximum GPU Length: 390mm - Maximum CPU Cooler Height: 160mm - Side Panel: 3mm Tempered Glass - Expansion Slots: 7 - Storage: Up to 3 x 2.5" SSD or 1 x 2.5" SSD + 2 x 3.5" HDD - Front I/O: Reset, Audio Out, Mic In, USB Type-A, 2 x USB 5Gbps (Type-A) - Dust Filter: Magnetic, top position - ARGB: Daisy-chain, MSI Mystic Light compatible - Warranty: 1 Year
Datasheet
| Warranty | 1 Year |
|---|---|
| Form Factor | ATX, mATX, Mini-ITX |
| color | Black |
| Note*** | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only |
| Material | Tempered Glass |
| I/O Panel | Reset Button, Audio-Out, Mic-In, USB Type-A |
| Cabinet Size | MID-TOWER |
| Dust Filters | Top |
| Max 2.5" SSD | 1 |
| Max 3.5" HDD | 2 |
| Max GPU Length | 390mm |
| Expansion Slots | 7 |
| Max Fan Support | 11 |
| Radiator Support | 360mm,280mm,240mm,140mm,120mm |
| Pre Installed Fans | 4 |
| Max CPU Cooler Height | 160mm |
