MSI MAG X870E Tomahawk Wifi DDR5 AMD Motherboard

The MSI MAG X870E Tomahawk WiFi is an ATX-form-factor motherboard built on the AMD X870E chipset for the AM5 socket, supporting AMD Ryzen 9000, 8000, and 7000 series desktop processors. It is engineered to deliver a stable, durable, and DIY-friendly platform for high-performance gaming and content-creation PCs. Power delivery is handled by a 14+2+1 digital power-phase design paired with dual 8-pin CPU power connectors and 80 A Smart Power Stages. The 8-layer PCB uses 2 oz thickened copper and server-grade materials, providing robust signal integrity under sustained loads. Memory support covers DDR5 in dual-channel configuration, with speeds reaching DDR5-8400+ MT/s under overclocking. Maximum supported capacity is 256 GB. The board supports AMD EXPO, JEDEC, and standard AMD POR frequencies, as well as CUDIMM in clock-driver bypass mode. For expansion, the primary PCIe slot (PCI_E1) is a PCIe 5.0 x16 lane directly from the CPU for Ryzen 9000 and 7000 series, dropping to PCIe 4.0 x8 or x4 for certain Ryzen 8000 APUs. An additional PCIe 4.0 x4 slot and a PCIe 3.0 x1 slot are available from the chipset. M.2 storage is covered by Lightning Gen 5 x4 support, complemented by MSI's EZ M.2 Shield Frozr II heatsinks and tool-free EZ M.2 Clip II retention. Connectivity is led by Wi-Fi 7 with Bluetooth 5.4 and a 5G wired LAN port. The rear I/O includes USB 40 Gbps Type-C, USB 10 Gbps Type-C and Type-A, USB 5 Gbps Type-A, and USB 2.0 ports alongside an HDMI output, two Type-C DisplayPort outputs, Flash BIOS Button, and Clear CMOS Button. Internally, the board provides four USB 2.0 ports, four USB 5 Gbps Type-A headers, and one USB 20 Gbps Type-C header, plus six system-fan headers, three ARGB V2 headers, one RGB header, and a TPM 2.0 pin header. Thermal management is addressed by the Frozr Guard system: an extended VRM heatsink with 7 W/mK MOSFET thermal pads, additional choke thermal pads, and an enlarged chipset heatsink designed to reduce dust accumulation and maintain heat-dissipation efficiency. Audio is handled by MSI's Audio Boost 5 solution. The EZ PCIe Release button allows single-tap GPU removal. Key Verified Specifications: - Socket: AM5 | Chipset: AMD X870E - CPU Support: Ryzen 9000, 8000, 7000 series - Memory: DDR5, dual-channel, up to 8400+ MT/s (OC), max 256 GB - Primary PCIe Slot: PCIe 5.0 x16 (CPU; Ryzen 9000/7000) - M.2: Lightning Gen 5 x4 support - Networking: Wi-Fi 7, Bluetooth 5.4, 5G LAN - Rear USB: 40 Gbps Type-C, 10 Gbps Type-C, 10 Gbps Type-A (×2), 5 Gbps Type-A - Display Outputs: 1× HDMI, 2× Type-C DisplayPort - Form Factor: ATX | Warranty: 3 Years
