MSI RTX 5060 Ventus 2X OC V1 8GB GDDR7 Graphics Card

The MSI RTX 5060 Ventus 2X OC V1 is a mainstream gaming graphics card built on the NVIDIA Blackwell architecture, bringing the latest GPU generation to a compact, dual-fan form factor. At its core sits the GeForce RTX 5060 chip with 3840 CUDA cores and 8 GB of GDDR7 memory running across a 128-bit bus at an effective speed of 28 Gbps, delivering responsive performance in modern titles and creative workloads alike. Cooling is handled by MSI's TORX Fan 5.0 technology. Two fans feature blades linked by ring arcs set at a 23-degree tilt, a design MSI states increases airflow by 23% compared to conventional axial fans. Beneath the fans sits a heatsink serviced by heat pipes that draw thermal energy away from the GPU die efficiently. A reinforcing backplate with an integrated airflow vent allows exhaust heat to pass directly through the card, reducing recirculation inside the chassis. When GPU temperatures remain low, the Zero Frozr feature halts both fans entirely, resulting in a completely silent idle state; they resume automatically once load demands active cooling. The Ventus line is designed around a neutral, build-agnostic aesthetic—a clean enclosure that suits both windowed and closed cases without dominating the visual theme. MSI Center software provides real-time monitoring and tuning, while the widely adopted MSI Afterburner utility allows granular clock and voltage control for enthusiasts who want to push the hardware further. The card connects via PCIe 5.0 and supports up to four displays simultaneously through its HDMI and DisplayPort outputs, reaching resolutions up to 7680×4320 (8K). DLSS 4 support enables AI-powered frame generation and upscaling for compatible titles. A single 8-pin power connector is required, and MSI recommends a minimum 550 W system PSU. Verified Specifications: • GPU: NVIDIA GeForce RTX 5060 (Blackwell architecture) • CUDA Cores: 3840 • Memory: 8 GB GDDR7, 128-bit interface • Memory Speed: 28 Gbps effective • Boost Clock: 2527 MHz (OC mode via MSI Center: 2535 MHz) • PCI Express: 5.0 • Display Outputs: HDMI + DisplayPort (up to 4 displays) • Max Resolution: 7680×4320 • Power Connector: 1× 8-pin • Recommended PSU: 550 W • DirectX: 12 Ultimate | OpenGL: 4.6 • Warranty: 3 Years
