Noctua NH-L9a-AM5 Low-Profile 92mm CPU Air Cooler for AMD AM5

The Noctua NH-L9a-AM5 is a low-profile CPU air cooler engineered specifically for AMD AM5 (LGA1718) processors, making it an ideal thermal solution for HTPC and Small Form Factor builds where vertical space is at a premium. With a total installed height of just 37mm — comprising a 23mm heatsink body and the slim 14mm-thick NF-A9x14 fan — it slips comfortably into compact cases that would reject any standard-height cooler. The heatsink’s footprint is sized to remain within AMD’s socket keep-out zone, meaning neither the fins nor the fan overhang the DIMM slots or the PCIe slot. Users building on tightly packed mini-ITX motherboards therefore retain full access to tall memory modules, PCIe add-in cards, and near-socket headers without any clearance compromises. Cooling performance is delivered through copper heatpipes soldered directly to aluminium fins — not press-fitted — which prevents the thermal-cycling gap degradation that can affect lesser coolers over time. The base and heatpipes are copper with nickel plating, and all joints are soldered for long-term reliability. The included NF-A9x14 HS-PWM fan features Noctua’s SSO2 bearing and supports fully automatic speed control via PWM. It spins between 600 RPM (at 20% PWM signal) and 2500 RPM at its peak, producing a maximum of 23.6 dB(A) of acoustical noise and delivering up to 57.5 m³/h of airflow. For near-silent operation, the bundled NA-RC7 Low-Noise Adaptor (LNA) caps fan speed at 1800 RPM, reducing noise to just 14.8 dB(A) and airflow to 40.8 m³/h — a worthwhile trade-off for lightly loaded Ryzen 5, Ryzen 7, or Ryzen 9 systems. The custom SecuFirm2™ AM5 mounting kit attaches through the stock AM5 backplate holes, resulting in a straightforward, tool-friendly installation. Optional NM-AM4-L9aL9i hardware (available separately from Noctua) allows the same cooler to be retrofitted to AM4 platforms. NT-H1 thermal compound, a Noctua metal case badge, and screws for optional 92×92×25mm fan upgrades round out the package. Noctua backs the NH-L9a-AM5 with a 6-year manufacturer’s warranty. The NF-A9x14 fan carries an MTTF rating of more than 150,000 hours. Verified Specifications: • Model: NH-L9a-AM5 • Socket: AMD AM5 (LGA1718) • Height with fan: 37 mm | Without fan: 23 mm • Width with fan: 95 mm | Without fan: 114 mm • Depth (both configurations): 92 mm • Weight with fan: 465 g | Without fan: 390 g • Heatsink material: Copper base & heatpipes, aluminium fins, soldered joints, nickel plating • NSPR: 61 • Fan model: Noctua NF-A9x14 HS-PWM • Fan bearing: SSO2 • Fan speed range: 600–2500 RPM (±10%); 1800 RPM max with LNA • Max airflow: 57.5 m³/h; 40.8 m³/h with LNA • Max noise: 23.6 dB(A); 14.8 dB(A) with LNA • Fan input power: 2.52 W at 12 V • Fan MTTF: >150,000 hours • Warranty: 6 years
