Nzxt H5 Flow 2024 Edition E-ATX Mid Tower Case

The NZXT H5 Flow 2024 Edition (model CC-H52FB-01) is a compact mid-tower chassis engineered around one priority: airflow. Ultra-fine mesh panels on the front, top, and side panel allow air to move freely through the enclosure, while simultaneously trapping dust before it reaches your components. The perforated PSU shroud — open on its side and bottom faces — creates a dedicated intake path for up to two 120 mm fans mounted beneath (fans not included), channelling cool air directly toward the GPU rather than letting it mix with the rest of the chassis thermals. For builders who prefer liquid cooling, the H5 Flow accommodates a 360 mm radiator across the front and a 240 mm radiator (or 280 mm with low-profile memory) at the top, making it compatible with high-performance all-in-one coolers such as the NZXT Kraken 360. Two NZXT F120Q 120 mm fans are pre-installed — one front intake, one rear exhaust — running at 1,350 ± 150 RPM, delivering 60.2 CFM of airflow at 24.1 dBA and 1.05 mm-H₂O static pressure via a 3-pin DC connector, so the system is ready to cool from the moment you power The case supports motherboards up to E-ATX (up to 277 mm wide), ATX, Micro-ATX, and Mini-ITX, giving it wide platform compatibility. GPU clearance reaches 410 mm, CPU cooler height up to 170 mm, and PSU length up to 200 mm. Cable routing is handled by wide channels, integrated hooks, and hook-and-loop straps, with up to 28.7 mm of clearance behind the motherboard tray. Storage options include two 2.5-inch SSD bays and one 3.5-inch HDD bay. Seven standard expansion slots and a clean front I/O — one USB 3.2 Gen 1 Type-A, one USB 3.2 Type-C, and a combined headset audio jack — round out the practical connectivity. Construction relies on SGCC steel for the chassis and dark-tinted tempered glass for the side panel, keeping the build sturdy while providing a clear view of the interior. Tool-less panel access (front, side, and top) speeds up installation and maintenance. The unit is covered by NZXT's 2-year warranty. Verified Specifications: - Model: CC-H52FB-01 | Color: Black - Dimensions: 465 mm H × 225 mm W × 430 mm D | Weight: 7.28 kg - Motherboard support: E-ATX (≤277 mm wide), ATX, Micro-ATX, Mini-ITX - Fan support: Front 3×120/2×140 mm | Top 2×120/2×140 mm | Bottom 2×120 mm | Rear 1×120 mm - Radiator support: Front up to 360 mm | Top up to 240 mm (280 mm low-profile memory) - Pre-installed fans: 2× F120Q (3-pin DC) — 1,350 ±150 RPM, 60.2 CFM, 24.1 dBA - GPU clearance: up to 410 mm | CPU cooler: up to 170 mm | PSU: up to 200 mm - Drive bays: 2× 2.5" SSD, 1× 3.5" HDD | Expansion slots: 7 - Front I/O: 1× USB 3.2 Type-A, 1× USB 3.2 Type-C, 1× headset audio jack - Material: SGCC Steel + Dark Tinted Tempered Glass | Warranty: 2 Years
